EN67
Controls
1 Monitor Open Button
[PUSH OPEN] ..................................... 墌 pg. 14
2 Dioptre Adjustment Control ................... 墌 pg. 8
3 Battery Release Button
[BATTERY RELEASE] .............................. 墌 pg. 7
4 •MENU Wheel [+, –, PUSH] ............... 墌 pg. 22
•LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. 墌 pg. 14
5 Snapshot Button
[SNAPSHOT] ........................... 墌 pg. 16, 17, 47
6 •Power Zoom Lever [T/W] .................. 墌 pg. 18
•Speaker Volume Control [VOL.] ........ 墌 pg. 31
7 Snapshot Mode Button
[MODE] ........................................ 墌 pg. 16, 17
8 OPEN/EJECT Switch ............................. 墌 pg. 10
9 Stop Button [5] ................................... 墌 pg. 31
0 •Rewind Button [
2
] ......................... 墌 pg. 31
•BACKLIGHT Button .......................... 墌 pg. 29
! Play/Pause Button [
4
/6] ...................... 墌 pg. 31
@ •Fast-Forward Button [
3
] ................. 墌 pg. 31
•FOCUS Button .................................. 墌 pg. 21
# Power Switch
[ , , , OFF] ........................... 墌 pg. 13
$ Recording Start/Stop Button .................. 墌 pg. 14
% Lock Button ......................................... 墌 pg. 13
^ VIDEO/DSC Switch [VIDEO, ] ...... 墌 pg. 13
& Video Light Switch
[LIGHT OFF/AUTO/ON] ...................... 墌 pg. 20
Connectors
To connect cables to the following connectors
*
and
(
,
open the LCD monitor.
* PC (DIGITAL PHOTO) Connector ........ 墌 pg. 42
( J Terminal/Edit Connector [JLIP (Joint Level
Interface Protocol)/EDIT] ...................... 墌 pg. 53
•Connect the editing cable when performing
Random Assemble Editing.
•Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
) DC Input Connector .............................. 墌 pg. 7
The connectors
q
to
e
are located beneath a cover.
q Audio/Video Output Connector
[AV] ........................................ 墌 pg. 40, 44, 53
w Digital Video Connector
[DV IN/OUT: GR-DVL309/DVL109, DV OUT:
GR-DVL308/DVL108]
(i.link*) .................................... 墌 pg. 42, 43, 45
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
e S-Video Output Connector [S] ... 墌 pg. 40, 44, 53
Indicators
r Tally Lamp ........................................... 墌 pg. 14
t Side LED Indicator
(GR-DVL309/DVL308 only) ................. 墌 pg. 24
y Power Lamp ........................................ 墌 pg. 14
Other Parts
u •Remote Sensor .................................. 墌 pg. 48
•Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
i Viewfinder ............................................. 墌 pg. 8
o Video Light .......................................... 墌 pg. 20
p Stereo Microphone .............................. 墌 pg. 58
Q Shoulder Strap Eyelets ............................ 墌 pg. 8
W Grip Strap .............................................. 墌 pg. 8
E Battery Pack Mount ............................... 墌 pg. 7
R LCD Monitor ................................. 墌 pg. 14, 15
T Speaker ............................................... 墌 pg. 31
Y Stud Hole .............................................. 墌 pg. 8
U Tripod Mounting Socket ......................... 墌 pg. 8
I MEMORY CARD Cover ....................... 墌 pg. 11
To Next Page
