90 EN
SPECIFICATIONS
Camcorder
For General
Power supply : DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.3 W
LCD monitor on, viewfinder off : Approx. 5.3 W
Video light : Approx. 3.5 W
Dimensions (W x H x D) : 83 mm x 97 mm x 188 mm (3-5/16" x 3-7/8" x 7-7/16")
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 610 g (1.4 lbs)
(GR-DVL817/DVL517)
Approx. 600 g (1.4 lbs)
(GR-DVL515/DVL317)
Operating temperature :0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Pickup : 1/4" CCD
Lens : F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens
Filter diameter : ø37 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL817/DVL517)
3" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL515/DVL317)
Viewfinder : Electronic viewfinder with 0.44" color LCD
(GR-DVL515)
Electronic viewfinder with 0.24" black/white LCD
(GR-DVL817/DVL517/DVL317)
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : NTSC standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
