98 EN
USER MAINTENANCE
After Use
1
Turn off the camcorder.
2
Slide down OPEN/EJECT in the direction of the
arrow, then swing the cover open until it locks. The
cassette holder opens automatically. Remove the
cassette.
3
Press “PUSH HERE” to close the cassette cover.
4
Open the card cover, then press EJECT. The
MultiMediaCard is disengaged from the camcorder.
Remove the MultiMediaCard.
5
Close the card cover.
6
Slide down BATT. RELEASE and remove the battery
pack.
Cleaning The Camcorder
1
CLEAN EXTERIOR
Wipe gently with a soft cloth.
•Put cloth in diluted mild soap and wring it well to
wipe off heavy dirt. Then wipe again with a dry
cloth.
2
CLEAN LCD MONITOR
Wipe gently with the provided cleaning cloth or a
commercially available soft cloth. Be careful not to
damage the monitor. Close the LCD monitor.
3
CLEAN LENS
Blow it with a blower brush, then wipe gently with
lens cleaning paper.
4
PULL OUT VIEWFINDER FULLY
5
CLEAN VIEWFINDER
Slide the cover in the direction of the arrow 1. Insert
a lens blower or a soft cloth into the gap at the
bottom of the viewfinder and clean the interior of the
viewfinder with it 2.
6
PUSH VIEWFINDER BACK IN
Close the cover until it locks in place. Push the
viewfinder back in.
2
1
BATT. RELEASE
Switch
Remove.
OPEN/EJECT Switch
PUSH HERE
Gap
Blower brush
Bottom of
viewfinder
Cassette holder
EJECT
NOTES:
●
Avoid using strong cleaning agents such as
benzine or alcohol.
●
Cleaning should be done only after the
battery pack has been removed or other
power units have been disconnected.
●
Mold may form if the lens is left dirty.
●
When using a cleaner or chemically treated
cloth refer to the cautions of each product.
