66 EN
30°
30°
5m
1
3
2
+
–
+
–
The Full-Function Remote Control Unit can operate
this camcorder from a distance as well as the basic
operations (Playback, Stop, Pause, Fast-Forward and
Rewind) of your VCR. It also makes additional
playback functions possible.
Installing The Batteries
The remote control uses two “AAA (R03)” size
batteries. See “General Battery Precautions”
( pg. 93).
1
Remove the battery compartment cover while
pushing up the tab as illustrated.
2
Insert two “AAA (R03)” size batteries in the
correct direction.
3
Re-attach the battery compartment cover.
USING THE REMOTE CONTROL UNIT
When using the remote control, be sure to point it
at the remote sensor. The illustration shows the
approximate transmitted beam effective area for
indoor use.
The transmitted beam may not be effective or may
cause incorrect operation outdoors or when the
remote sensor is directly exposed to sunlight or
powerful lighting.
Transmitted beam
effective area
Remote sensor
Tab
