50 EN
USER MAINTENANCE
After Use
1
Set the Power Switch to “POWER OFF” to turn off
the camcorder.
2
Open the LCD monitor to an angle of over 60
degrees. Slide EJECT to open the cassette holder, then
remove the cassette.
3
Close and lock the cassette holder by pressing PUSH.
4
Close and lock the LCD monitor.
5
Slide BATTERY RELEASE to remove the battery pack.
6
Turn the LENS COVER Open/Close Ring to close
the lens cover.
Cleaning The Camcorder
1
CLEAN EXTERIOR
Wipe gently with a soft cloth.
•Put cloth in diluted mild soap and wring it well to
wipe off heavy dirt, then wipe again with a dry
cloth.
2
CLEAN LCD MONITOR
Open the LCD monitor and wipe it gently with a soft
cloth. Be careful not to damage the monitor. Close
the LCD monitor.
3
CLEAN LENS
Blow it with a blower brush, then wipe it gently with
lens cleaning paper.
4
REMOVE EYEPIECE
Turn the eyepiece counterclockwise and pull it out.
5
CLEAN VIEWFINDER
Remove dust using a blower brush.
6
RE-ATTACH EYEPIECE
Re-attach the eyepiece and turn it clockwise.
Remove.
PUSH
LENS COVER Open/Close Ring
EJECT
Set to “POWER OFF”.
BATTERY RELEASE
NOTES:
●
Avoid using strong cleaning agents such as benzine or alcohol.
●
Cleaning should be done only after the battery pack has been removed or other power units have been
disconnected.
●
Mould may form if the lens is left dirty.
●
When using a cleaner or chemically treated cloth, refer to the cautions that came with it.
●
When removing the eyepiece, be sure to hold the viewfinder securely.
