14 EN
GETTING STARTED
This camera’s 2-way power supply system lets
you choose the most appropriate source of
power. Do not use provided power supply units
with other equipment.
Charging the Battery Pack
1 Set the power switch to OFF.
2 With the arrow on the battery pack pointing
downward, push the battery pack slightly against
the battery pack mount.
● If the battery mount cover is attached, remove it
by sliding BATT.
3 Slide down the battery pack until it locks in
place.
4 Connect the AC adapter to the camera.
5 Connect the power cord to the AC adapter.
(AP-V14E only)
6 Plug the power cord into an AC outlet. The
power/charge lamp on the camera blinks to
indicate charging has started.
7 When the power/charge lamp goes out,
charging is finished. Unplug the power cord from
the AC outlet. Disconnect the AC adapter from
the camera.
To detach the battery pack
While sliding BATT., remove the battery pack.
* Provided
Power
Power/Charge Lamp
Battery Pack Mount
AC Adapter
(ex. AP-V17E)
Open the cover.
Power Switch
To DC connector
Lock Button
BATT.
Arrow
Battery Pack
To AC outlet
Required charging time
Battery pack Charging time
BN-VF707U* Approx. 1 hr. 30 min.
BN-VF714U Approx. 2 hr. 40 min.
BN-VF733U Approx. 5 hr. 40 min.
To Next Page
