English
Thank you for purchasing this JVC product. Before you begin operating this unit, please read the operating instructions carefully to be sure you enjoy the best possible performance. If you have any
questions, please consult your JVC dealer.
To reduce the risk of electrical shocks, fire, etc.
• Do not remove screws, cover or cabinet.
• Do not expose this appliance to rain or moisture.
• Do not disassemble or modify the unit.
• Do not allow flammable, water or metallic objects to enter the unit.
For your safety...
• In dryer air conditions such as in winter, you may feel some static shock when using the headphones.
• Should you start to feel ill while using the headphones, you should stop using them immediately.
• Be sure that your hair or any other objects do not get caught in the headband slider (adjuster) when
adjusting the headband.
Avoid using the headphones...
• in places subject to excessive humidity or dust
• in places subject to extremely high (over 40 °C or 104 °F) or low (under 5 °C or 41 °F) temperatures
CAUTION
Specifications
Power supply/General
Power supply Internal rechargeable lithium battery
Frequency response 20 Hz - 20 000 Hz
Battery life Approx. 17 hrs (Depends on usage conditions.)
Charging time Approx. 3 hrs
Usage temperature range 5 °C (41 °F) to 40 °C (104 °F)
Mass S50BT: 145 g (5.11oz), S40BT: 146 g (5.15oz), S30BT: 143 g (5.04oz)
(including internal rechargeable battery)
Accessories Charging cable
Designs and specifications are subject to change without notice.
PARTS (right side)
(to AC adaptor)
CHARGING
The indicator lights up in red, and charging starts. When charging is complete, the indicator goes out.
• When the remaining battery power is low, the indicator flashes red slowly and the alarm sounds every
4 minutes.
• Operation is not possible while charging.
CONNECTING
When the power is off, hold the POWER button down (for at least 7 seconds) until the indicator flashes
alternately in red and blue.
Select “JVC HA-S50BT”(“JVC HA-S40BT”,”JVC HA-S30BT”) from the device list. The indicator flashes in blue
when pairing is complete. During the pairing process, the other device may require input of a PIN code. In
such a case, enter “0000” as the PIN code for the System.
ON and OFF
hold down
ON : The indicator lights up in blue for 1 second. The indicator flashes
slowly in blue when the unit is connected, and flashes slowly in red
when the unit is not connected.
OFF : The indicator lights up in red for 1 second.
MUSIC PHONE
Answer End
Reject Transfer
DO NOT leave the headphones...
• exposed to direct sunlight
• near a heater
To protect the headphones, DO NOT...
• allow them to get wet
• shake them or drop them against hard objects
Precautions for use
• Do not use any cables other than the ones provided.
• Do not use supplied charging cable for any other equipment.
• The ear pads will wear out earlier than the other parts even in normal use or in normal storage due to the
material characteristics.
• For replacement of the ear pads, consult with the dealer where you purchased the headphones.
NOTE
If the System does not work correctly, charge the System to reset it.
BLUETOOTH
Standard BLUETOOTH v3.0 Class 2 Max. communication distance Approx. 10 m (33 ft)
Profiles A2DP/AVRCP/HSP/HFP Codecs SBC
Frequency range 2.042 GHz - 2.480 GHz Output power +4 dBm (MAX). 0 dBm (AVE) Power
Class 2
EUT has the power settings by the software as follows;
RF: GFSK Power:33, EDR Power: 27
Software: AB1500G Family Configuration Tool 2.5.23.0
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
JVCKENWOOD Corporation (JVC) is under licence. Other trademarks and trade names are those of their respective owners.
(S50BT)
POWER/SOUND
(S40BT, S30BT)
POWER/BASS
Indicator
VOL +
VOL -
Microphone Charging terminal
7
Sec.
hold down blue / red For HA-S50BT
Bluetooth
Device
JVC HA-S50BT
3
Sec.
VOL + VOL -
x 2 x 3
SOUND(S50BT)
BASS(S40BT, S30BT)
NORMAL
BASS CLEAR
NORMAL BASS
• If no BLUETOOTH device is connected for about 5 minutes, the System automatically turns itself off.
• When you turn on the unit for the first time after purchasing, the indicator flashes alternately in red and
blue and pairing begins automatically.
When you change the SOUND (BASS) mode, the unit beeps to indicate the current sound mode.
Beeps once: NORMAL / Beeps twice: BASS / Beeps 3 times: CLEAR
