3-9
CD changer mechanism
Block No. [M][A][M][M]
 Symbol No. Part No. Part Name Description Local
1 VKS1144-004 CHASSIS
2 VKS3698-003 TRAY GUIDE (x2)
3 VKS5532-003 PULLEY GEAR (x2)
4 VKB3000-164 BELT (x2)
5 VKS5505-003 GEAR B (x2)
6 VKS5506-002 GEAR C (x3)
7 VKS5507-002 CROSS GEAR U
8 VKS5508-002 CROSS GEAR L
9 VKS5510-003 SELECT LEVER
10 VKH5769-001 S.G.SHAFT
11 VKS5511-002 SELECT GEAR
12 VKW5155-003 COMP.SPRING
13 VKM3846-003 GEAR BRACKET
14 VKS5509-002MM CYLINDER GEAR
15 MSN-5D257A D. C MOTOR (x2)
16 QYSPSPD2616Z SCREW 2.6mm x 16mm(x2)
17 LV40612-001A COMP.SPRING
18 VKM3825-00B C.G.BASE ASSY
19 VKZ3172-00ASS CAM SW. R ASSY
20 VKZ3173-00ASS CAM SW. R ASSY
21 QYSPST2606Z TAP SCREW 2.6mm x 6mm(x3)
22 VKS2263-002MM CAM R1
23 VKS2264-002MM CAM R2
24 VKS2265-002MM CAM GEAR L
25 WDL316050MM SLIT WASHER
26 WDL316050MM SLIT WASHER
27 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x4)
28 VKS3702-00FMMVT DRIVE UNIT
29 VKS2247-005 MECHA HOLDER A
30 VKL7767-00D BRACKET ASSY
31 QYSBSF2606Z SCREW 2.6mm x 6mm(x2)
32 VKM3860-00E M.HOLDER B AS'Y
33 VKL7802-00D M.HOLDER C AS'Y
34 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
35 VKL7810-00B LIFTER ASSY R
36 VKL7811-00B LIFTER ASSY L
37 VKL7812-00B LIFTER ASSY H
38 VKL2745-003 LIFTER BASE
39 VKM3857-002 LIFTER BRACKET
40 QYSDST2604Z SCREW 2.6mm x 4mm
41 WDL266035-2 SLIT WASHER
42 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x4)
43 VKS5514-002MM LOCK LEVER (x3)
44 VKY3133-002MM RETURN SPRING
45 QYSBSF2608Z TAP SCREW 2.6mm x 8mm
46 VKY3134-003MM CLICK SPRING
47 VKS2252-00N TRAY ASSY (x3)
48 VKS2250-004 TOP BRACKET
49 VKS5515-002 S.TRAY STOPPER
50 VKW5156-004 TORSION SPRING
51 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x3)
52 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x2)
