JVC In-Dash DVD Player KD-LX50R Service Manual

Item Parts number Parts name Area
A
Packing
Q'ty Description
Block No. M4MM
P 1 QPA01703505P POLY BAG 2 INST BOOK
P 2 QPA00801205 POLY BAG 1 INST BOOK
P 3 QPC03004315P POLY BAG 1 SET
P 4 LV31735-001A CARTON 1
P 5 LV10193-201A PAPER CUSHION 2
P 6 LV20660-001A CARTON BOX 1 FOR VOICE UNIT
Item Parts number Parts name Area
A
Q'ty Description
Block No. M5MM
A 1 LVT0497-001A INST BOOK 1
A 2 BT-54013-1 WARRANTY CARD 1
A 3 LVT0519-001A INST SHEET 1
A 4 LVT0498-001A INST BOOK 1
A 5 LVT0432-001B INST MANUAL 1
A 6 LVT0433-001B INST MANUAL 1
A 7 LVT0434-001B INST MANUAL 1
A 8 LVT0334-002A CAUTION SHEET 1
A 9 VKZ4027-202 PLUG NUT 1
A 10 VKH4871-001SS MOUNT BOLT 1
A 11 VKZ4328-001 LOCK NUT 1
A 12 WNS5000Z WASHER 1
A 13 FSKL4010-002 HOOK 2
A 14 RM-RK32 REMOCON 1
A 15 QAB0014-001 BATTERY 1
A 16 QAM0267-001 CAR CABLE 1
A 17 QAN0036-002 MIC 1
A 18 QAL0229-002 KEY UNIT 1
A 19 LV40846-006A SPACER
(
F
)
1
A 20 QHX2075-001 WIRE CLAMP 1
A 21 FSKM2004-202 MOUNTING SLEEVE 1
A 22 LV10187-001A-N TRIM PLATE 1
A 23 LV40978-001A CAUTION SHEET 1
A 24 KD-LX50VOICE VOICE UNIT 1
KIT 1 KDGS717K-SCREW1 1 NO.9-13
parts list
parts list
Accessories
