22
ENGLISH
Prohibiting disc ejection
You can prohibit disc ejection and can lock a disc
in the loading slot.
While pressing CD, press and hold 0 for
more than 2 seconds.
“EJECT” flashes on the display for about 5 seconds,
and the disc is locked and cannot be ejected.
To cancel the prohibition and unlock the
disc
While pressing CD, press and hold 0 again for
more than 2 seconds.
“EJECT” appears on the display, and the disc
ejects from the loading slot.
Playing a CD Text
In a CD Text, some information about the disc (its
disc title, performer, and track title) is recorded.
This CD Text information will be shown
automatically when you play a CD Text.
To change the CD Text information
manually, select text display mode while
playing a CD Text.
Press DISP (display) repeatedly.
Each time you press the button,
the display changes as follows:
Notes:
The display shows up to 8 characters at one time
and scrolls if there are more than 8 characters.
See also “To select the scroll mode—SCROLL” on
page 32.
Some characters or symbols will not be shown (and
be blanked) on the display.
(Ex. “ABCå!d#” ]“ABCA D ”)
When you press DISP (display) while playing a
conventional CD, “NO NAME” appears for the
disc title/performer and the track title.
When track title is shown, the Tr indicator and
current track number also appear on the right side
of the display.
Disc title / performer
Track title
( lights up on the display)
Elapsed playing time and
Current track number
Clock and
Current track number
EN19-22_KD-G401[E_EX_EU]f.p65 7/11/03, 7:11 PM22

Other manuals for JVC KD-G401

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G401 and is the answer not in the manual?

JVC KD-G401 Specifications

Audio Amplifier IconAudio Amplifier
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS) (front)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output (RMS) (rear)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range (bass)±10 dB at 100 Hz
tone control range (treble)±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player IconCD Player
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (W × H × D)182 mm × 52 mm × 150 mm
panel size188 mm × 58 mm × 11 mm
mass1.3 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner IconTuner
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz)65 dB
frequency response40 Hz to 15 000 Hz
stereo separation30 dB
capture ratio1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
