JVC KD-R463 User Manual

ENGLISH
7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press
2 Turn the volume knob to select a preset number, then press the
knob to confirm.
Other settings
1
Press and hold .
2 Turn the volume knob to select [ TUNER ], then press the knob.
3 Turn the volume knob to make a selection (see the following table),
then press the knob.
4 Repeat step 3 until the desired item is selected/activated or follow
the instructions stated on the selected item.
5 Press to exit.
To return to the previous setting item, press .
Default:
XX
RADIO TIMER Turns on the radio at a specific time regardless of the current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the timer will be turned
on.
2 FM / AM :Select the source.
3 01 to 18 (for FM)/ 01 to 06 (for AM):Select the preset station.
4 Set the activation day *
1
and time.
“
M ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
• [
OFF ] is selected for [ AM ] in [ SRCSELECT ] after Radio Timer for AM is
selected. (
4 )
SSM SSM01–06 / SSM07–12 / SSM13–18 :Automatically presets up to
18 stations for FM. “SSM” stops flashing when the first 6 stations are stored.
Select
SSM07–12 / SSM13–18 to store the following 12 stations.
Default: XX
LOCAL SEEK *
2
ON :Searches only stations with good reception.; OFF :Cancels.
• Settings made are applicable only to the selected source/station. Once
you change the source/station, you need to make the settings again.
IF BAND *
2
AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not be
degraded and the stereo effect will remain.
MONO *
2
ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
NEWS-STBY *
2
ON :The unit will temporarily switch to News Programme if available.;
OFF :Cancels.
REGIONAL *
2
ON : Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET *
2
ON : Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF : Cancels.
TI SET *
2
ON : Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up). ;
OFF :Cancels.
PTY SEARCH Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
PTY code : NEWS , AFFAIRS , INFO , SPORT , EDUCATE , DRAMA , CULTURE , SCIENCE ,
VARIED , POP M (music), ROCK M (music), EASY M (music), LIGHT M (music),
CLASSICS , OTHER M (music), WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION ,
PHONE IN , TRAVEL , LEISURE , JAZZ , COUNTRY , NATION M (music), OLDIES , FOLK M
(music),
DOCUMENT
*
1
Selectable only when [ ONCE ] or [ WEEKLY ] is selected in step 1 .
*
2
Only for FM source.
JS_JVC_KD_R561_EU_EN_06_f.indd 7JS_JVC_KD_R561_EU_EN_06_f.indd 7 4/8/2014 12:12:07 PM4/8/2014 12:12:07 PM
