SPECIFICATIONS
USB
USB Standard USB1.1, USB2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/16/32
Maximum Supply Current DC5V
1A
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear-PCM
Auxiliary

Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1200mV
Input Impedance 30kΩ
Audio
Maximum Output Power 50W×4
Output Power
(DIN 45324, +B = 14.4 V)
30W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (CD) 2500mV/10kΩ load (full scale)
Preout Impedance ≤600Ω
General
Operating Voltage 14.4V (10.5V—16V allowable)
Maximum Current Consumption 10A
Operating Temperature Range 0°C to +40°C
Installation Size (W×H×D)
KD-R751 / KD-R651 :
182mm×53mm×159mm
Other models :
182mm×53mm×158mm
Weight
1.2k
g
Subject to change without notice.
TUNER
FM Frequency Range KD-R751 / KD-R651 / KD-R551 / KD-R453 /
KD-R452 / KD-R451 :
FM 87.5MHz to 108.0MHz (50kHz step)
KD-R757 / KD-R557 / KD-R457 :
FM 87.5MHz to 108.0MHz (50kHz step)
FM-LO 65.0MHz to 74.0MHz (30kHz step)
Usable Sensitivity (S/N=26dB) 0.71μV/75Ω
Quieting Sensitivity
(DINS/N=46dB)
2.0μV/75Ω
Frequency Response (±3dB) 30Hz to 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
AM Frequency Range MW 531kHz to 1611kHz (9kHz step)
LW 153kHz to 279kHz (9kHz step)
Usable Sensitivity (S/N=20dB) MW 28.2μV
LW 50μV
CD player
Laser Diode GaAIAs
Digital Filter 8 times over sampling
Spindle Speed 500 rpm — 200 rpm (CLV)
Wow & Flutter Below measurable limit
Frequency Response (±1dB) 20 Hz — 20 kHz
Total Harmonic Distortion (1 kHz) 0.01 %
Signal-to-Noise Ratio (1 kHz) 105 dB
Dynamic Range 90 dB
Channel Separation 85 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
