3-1
Area suffix
E ----------- Continental Europe
EX ------------ Northern Europe
EY ------------- Eastern Europe
EU ------------------------- Turkey
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD mechanism assembly and parts list (Block No.MB)
Electrical parts list (Block No.01~02)(KD-S1501_E.EX.EY.EU)
Electrical parts list (Block No.03~04)(KD-G152/KD-G151_E.EX.EY.EU)
Electrical parts list (Block No.05~06)(KD-S1501_E2.EX2.EY2.EU2)
Electrical parts list (Block No.07~08)(KD-G152/KD-G151_E2.EX2.EY2.EU2)
Packing materials and accessories parts list (Block No.M3)
