8
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/ANDROID
Start playback
The source changes automatically and playback starts.
CD
KD-T409/
KD-T402:
KD-T401:
*1 Do not leave the cable inside the car when not using.
*2 You can control Android device using the Android device itself via other media player
applications installed in the Android device.
Eject disc
Label side
Preparation:
You can listen to music from a portable audio player via the auxiliary input
jack.
• Select
[ON]
for
[BUILT-IN AUX]
in
[SOURCESELECT]
. (Page 5)
Start listening
1
Connect a portable audio player (commercially available).
3.5 mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
Auxiliary input jack
Auxiliary input jack
3.5 mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
2 Press source button repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
AUX
Eject disc
Label side
KD-T401:KD-T409/KD-T402:
KD-T401:
KD-T409/
KD-T402:
USB
USB input terminal
USB input terminal
USB 2.0 cable*1
(commercially available)
USB cable*1
(commercially available)
ANDROID*2
JS_JVC_KD_T409_E_EN_01.indd 8JS_JVC_KD_T409_E_EN_01.indd 8 5/30/2018 11:22:17 AM5/30/2018 11:22:17 AM
