JVC KD-T402 User Manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
ENGLISH
BASICS
To On the faceplate
Turn on the power
Press B SRC.
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Press the volume knob to mute the sound or pause playback.
• Press again to cancel. The volume level returns to the previous level before muting or pause.
Select a source
• Press B SRC repeatedly.
• Press B SRC, then turn the volume knob within 2 seconds.
Change the display information
Press
repeatedly. (Page 15)
Select an item
1 Turn the volume knob to select an item.
2 Press the knob to confirm.
Attach
How to reset
Detach
Faceplate
Your preset
adjustment will be
erased except stored
radio stations.
Volume knob
Loading slot
Detach button
Source button
Display window
KD-T409/KD-T402:
JS_JVC_KD_T409_E_EN_01.indd 3JS_JVC_KD_T409_E_EN_01.indd 3 5/30/2018 11:22:14 AM5/30/2018 11:22:14 AM

JVC KD-T402 Specifications

General

DIN size	1 DIN
Equalizer	Yes
Impedance	4 Ω
Output power	350 W
Product color	Black
Ready for iPod	No
Volume control	Rotary
Disc types supported	CD
Audio output channels	- channels
Equalizer bands quantity	15
Maximum power per channel	50 W
Mobile operating systems supported	Android
USB version	2.0
USB ports quantity	1
Audio formats supported	FLAC, MP3, WAV, WMA
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	1500 g

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	53 mm
Weight	1200 g
