12
Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television. Some of the
connection terminals are color coded for easy connection with the proper cables.
Front Panel
Side Panel
INPUT
MENU
CHANNEL
VOLUME
OK
BACK
POWER
PHOTO VIEWER
TV Basic Controls
TeleDock
Illumination for iPod
Power Lamp
Remote Control Sensor
Input
Change the input
MENU
Used to access the TV’s onscreen menus.
+CH–
Move sequentially through the channels.
+VOL–
Raises or lowers the volume.
POWER
Turn the TV on or off.
Photo Viewer Connector
• Do not use Photo Viewer connector to
connect the iPod
Notes:
• Do not use unreasonable force to the TeleDock.
• When not using the TeleDock, close the cover.
• Do not touch the connector pins of the TeleDock or the iPod terminal pins.
• Do not put different devices on the TeleDock. It may cause a connection failure.
LCT2385-001A-A English 12LCT2385-001A-A English 12 4/14/08 3:42:40 PM4/14/08 3:42:40 PM
