JVC LT-42DA9BJ Service Manual

(No.YA606<Rev.002>)3-3
EXPLODED VIEW PARTS LIST
 Ref.No. Part No. Part Name Description Local
LV1 HU-0130100002 DIGITAL(LVDS) CABLE
 1 HU-014213230PN REAR COVER
LT-26DA9BJ,LT-26DA9BU,LT-26DB9BD,LT-26DC9BH,LT-26ED91U
 1 HU-014213231PN REAR COVER LT-26DA9BN
 2 HU-014213210PN FRONT CABINET
LT-26DA9BJ,LT-26DA9BN,LT-26DA9BU,LT-26DB9BD,LT-26DC9BH
 2 HU-014213211PN FRONT CABINET LT-26ED91U
 3 QLD0550-001 LCD PANEL UNIT HU-0141300014 Inc.3A-3B
 3A V260B1-L01-TC2 LCD CONTROL PWB (V260B1-L01)
 3B V260B1-L01-IVC2 INVERTER PWB (V260B1-L01)
5 HU-024000450 SPEAKER 8
Ω 5W 2 pcs 1 set
6 HU-0210000001 BLUE LED MODULE
8 HU-3010119001CO MAIN SHIELD
10 HU-3025220001PN CONTROL KNOB
11 HU-3029406001PN GUIDE KNOB
12 HU-3010310001CO SIDE SHIELD
LT-26DA9BJ,LT-26DA9BN,LT-26DA9BU,LT-26DB9BD,LT-26ED91U
12 HU-3010310002CO SIDE SHIELD LT-26DC9BH
 13 HU-0120000001 AC INLET
14 HU-3011503001CO POWER BRACKET
16 HU-3022116001PN STAND BASE
17 HU-014213250 HINGE ASSY
LT-26DA9BJ,LT-26DA9BU,LT-26DB9BD,LT-26DC9BH,LT-26ED91U
17 HU-014213251 HINGE ASSY LT-26DA9BN
18 HU-014213240CO BASE BRACKET ASSY
19 HU-M1308420815 SCREW M4x8(x4)
20 HU-M1118300615 SCREW M3x6(x2)
21 HU-M1305300817 SCREW M3x8(x7)
22 HU-M1100400617 SCREW M4x6(x4)
25 HU-3011305001CO PANEL BRACKET (x2)
30 HU-0130100009 E-HARNESS ASSY MAIN-IR
31 HU-0130100007 E-HARNESS ASSY MAIN-KEY
32 HU-0130100013 E-HARNESS ASSY MAIN-POWER UNIT
33 HU-0130100022 E-HARNESS ASSY INVERTER-POWER UNIT
 101 HU-71200009 MAIN PWB
LT-26DA9BJ,LT-26DA9BU,LT-26DB9BD
 101 HU-71200026 MAIN PWB LT-26DA9BN,LT-26DC9BH,LT-26ED91U
 102 HU-71200005 MPEG PWB LT-26DA9BJ,LT-26DA9BN,LT-26DA9BU,LT-26ED91U
 102 HU-71200006 MPEG PWB LT-26DB9BD
 102 HU-71200012 MPEG PWB LT-26DC9BH
 103 HU-72200001 IR PWB
 104 HU-72200002 KEY PWB
 105 HU-014031300 POWER UNIT
 107 HU-014070200 SMART DTV PWB LT-26DC9BH
