JVC LT-42DA9BJ Service Manual

(No.YA606<Rev.002>)3-15
PRINTED WIRING BOARD PARTS LIST [LT-26DA9BN, LT-26ED91U]
MAIN P.W. BOARD ASS'Y (HU-71200026)
 Ref No. Part No. Part Name Description Local
U2 HU-004020013 FET
U60 HU-000010440 IC PROCESSOR
U120 CD4052BM-X IC MUX/DEMUX
U180 HU-000060019 IC OP AMP
U200 HU-000990180 IC SWITCH
U470 HU-000230270 IC HDMI RECEIVER
U560 HU-000140450 IC AUDIO DAC
U580 TPA3100D2PHP-W IC AUDIO AMP
U581 HU-000060510 IC HEADPHONE AMP
U630 HU-004020250 FET
U660 HU-000170030 IC RS232 DRIVER
U661 SN74LVC244APW-X IC CMOS
U720 HU-000140583 IC DC-DC CONV
U721 HU-000091100 IC REGULATOR
U723 HU-000091100 IC REGULATOR
U725 HU-000091100 IC REGULATOR
U726 BA50BC0WFP-X IC REGULATOR
U770 HU-014040950 TUNER ANALOG
U771 HU-000090090 IC REGULATOR
U772 HU-0009000001 IC POWER SW
U800 HU-000990055 IC
VOLTAGE DETECTOR
U801 HU-000010610 IC MICOM
Q1 HU-004001001 TRANSISTOR
Q61 HU-004001001 TRANSISTOR
Q120 HU-004001001 TRANSISTOR
Q374 HU-004001001 TRANSISTOR
Q375 HU-004001001 TRANSISTOR
Q581 HU-004001001 TRANSISTOR
Q582 HU-004020030 MOS FET
Q583 HU-004001001 TRANSISTOR
Q631 HU-004001001 TRANSISTOR
Q632 HU-004001001 TRANSISTOR
Q634 HU-004000260 FET
Q660 HU-004001001 TRANSISTOR
Q661 HU-004000260 FET
Q662 HU-004000260 FET
Q680 HU-004000008 TRANSISTOR
Q681 HU-004001001 TRANSISTOR
Q686 HU-004000008 TRANSISTOR
Q773 HU-004001001 TRANSISTOR
Q800 HU-004000260 FET
Q802 HU-004000260 FET
Q803 HU-004001001 TRANSISTOR
D1 HU-003010046 Z DIODE
D370 HU-003040008 SI DIODE
D371 HU-003040008 SI DIODE
Z330 HU-003010053 Z DIODE
Z331 HU-003010053 Z DIODE
C3 HU-001060286 C CAPACITOR 10uF 10V
C4 HU-001060250 C CAPACITOR 0.1uF 16V K
C5 HU-001060286 C CAPACITOR 10uF 10V
C6 HU-001060250 C CAPACITOR 0.1uF 16V K
C7 HU-001060250 C CAPACITOR 0.1uF 16V K
C8 HU-001060286 C CAPACITOR 10uF 10V
C9 HU-001060250 C CAPACITOR 0.1uF 16V K
C10 HU-001060236 C CAPACITOR 10uF 25V
C11 HU-001060250 C CAPACITOR 0.1uF 16V K
C12 HU-001060249 C CAPACITOR 100pF 50V J
C13 HU-001060286 C CAPACITOR 10uF 10V
C14 HU-001060250 C CAPACITOR 0.1uF 16V K
C15 HU-001060286 C CAPACITOR 10uF 10V
C16 HU-001060250 C CAPACITOR 0.1uF 16V K
C17 HU-001060286 C CAPACITOR 10uF 10V
C18 HU-001060250 C CAPACITOR 0.1uF 16V K
C19 HU-001060286 C CAPACITOR 10uF 10V
C20 HU-001060250 C CAPACITOR 0.1uF 16V K
C21 HU-001060286 C CAPACITOR 10uF 10V
C22 HU-001060250 C CAPACITOR 0.1uF 16V K
C23 HU-001060286 C CAPACITOR 10uF 10V
C24 HU-001060250 C CAPACITOR 0.1uF 16V K
C25 HU-001060286 C CAPACITOR 10uF 10V
C26 HU-001060250 C CAPACITOR 0.1uF 16V K
C27 HU-001060250 C CAPACITOR 0.1uF 16V K
C28 HU-001060286 C CAPACITOR 10uF 10V
C29 HU-001060286 C CAPACITOR 10uF 10V
C30 HU-001060219 C CAPACITOR 1000pF 50V K
C31 HU-001060219 C CAPACITOR 1000pF 50V K
C32 HU-001060250 C CAPACITOR 0.1uF 16V K
C33 HU-001060250 C CAPACITOR 0.1uF 16V K
C34 HU-001060250 C CAPACITOR 0.1uF 16V K
C35 HU-001060286 C CAPACITOR 10uF 10V
C36 HU-001060250 C CAPACITOR 0.1uF 16V K
C37 HU-001060286 C CAPACITOR 10uF 10V
C38 HU-001060250 C CAPACITOR 0.1uF 16V K
C39 HU-001060286 C CAPACITOR 10uF 10V
C40 HU-001060250 C CAPACITOR 0.1uF 16V K
C41 HU-001060250 C CAPACITOR 0.1uF 16V K
C42 HU-001060321 C CAPACITOR 10uF 10V K
C43 HU-001060250 C CAPACITOR 0.1uF 16V K
C44 HU-001060236 C CAPACITOR 10uF 25V
C45 HU-001060105 C CAPACITOR 0.1uF 50V
C46 HU-001060236 C CAPACITOR 10uF 25V
C47 HU-001060236 C CAPACITOR 10uF 25V
C60 HU-001060250 C CAPACITOR 0.1uF 16V K
C64 HU-001060250 C CAPACITOR 0.1uF 16V K
C66 HU-001063002 C CAPACITOR 14pF 50V
C67 HU-001063002 C CAPACITOR 14pF 50V
C120 HU-001060288 C CAPACITOR 1uF 25V
C121 HU-001060288 C CAPACITOR 1uF 25V
C122 HU-001060288 C CAPACITOR 1uF 25V
C123 HU-001060318 C CAPACITOR 0.1uF 50V
C124 HU-001060318 C CAPACITOR 0.1uF 50V
C125 HU-001060318 C CAPACITOR 0.1uF 50V
C126 HU-001060288 C CAPACITOR 1uF 25V
C127 HU-001060288 C CAPACITOR 1uF 25V
C128 HU-001060288 C CAPACITOR 1uF 25V
C129 HU-001060318 C CAPACITOR 0.1uF 50V
C130 HU-001060288 C CAPACITOR 1uF 25V
C131 HU-001060318 C CAPACITOR 0.1uF 50V
C132 HU-001060318 C CAPACITOR 0.1uF 50V
C133 HU-001060288 C CAPACITOR 1uF 25V
C134 HU-001060288 C CAPACITOR 1uF 25V
C135 HU-001060288 C CAPACITOR 1uF 25V
C136 HU-001060288 C CAPACITOR 1uF 25V
C137 HU-001060288 C CAPACITOR 1uF 25V
C138 HU-001060288 C CAPACITOR 1uF 25V
C145 HU-001060266 C CAPACITOR 56pF 50V J
C146 HU-001063035 C CAPACITOR 10pF 50V C
C147 HU-001060250 C CAPACITOR 0.1uF 16V K
C148 HU-001060266 C CAPACITOR 56pF 50V J
C149 HU-001060286 C CAPACITOR 10uF 10V
C150 HU-001060318 C CAPACITOR 0.1uF 50V
C151 HU-001060219 C CAPACITOR 1000pF 50V K
C152 HU-001060288 C CAPACITOR 1uF 25V
C153 HU-001060219 C CAPACITOR 1000pF 50V K
C154 HU-001060288 C CAPACITOR 1uF 25V
C155 HU-001060236 C CAPACITOR 10uF 25V
C156 HU-001060219 C CAPACITOR 1000pF 50V K
C158 HU-001060219 C CAPACITOR 1000pF 50V K
C159 HU-001060219 C CAPACITOR 1000pF 50V K
C160 HU-001060219 C CAPACITOR 1000pF 50V K
C161 HU-001060288 C CAPACITOR 1uF 25V
C162 HU-001060219 C CAPACITOR 1000pF 50V K
C163 HU-001060288 C CAPACITOR 1uF 25V
C164 HU-001060219 C CAPACITOR 1000pF 50V K
C166 HU-001060236 C CAPACITOR 10uF 25V
C180 HU-001071194 E CAPACITOR 100uF 25V
C181 HU-001060318 C CAPACITOR 0.1uF 50V
C182 HU-001060318 C CAPACITOR 0.1uF 50V
C183 HU-001071228 E CAPACITOR 470uF 16V
C186 HU-001071228 E CAPACITOR 470uF 16V
C200 HU-001060286 C CAPACITOR 10uF 10V
C201 HU-001060236 C CAPACITOR 10uF 25V
C202 HU-001060297 C CAPACITOR 0.01pF 50V K
C203 HU-001060250 C CAPACITOR 0.1uF 16V K
C204 HU-001060318 C CAPACITOR 0.1uF 50V
C205 HU-001060286 C CAPACITOR 10uF 10V
C206 HU-001060224 C CAPACITOR 0.47uF 16V
C207 HU-001060250 C CAPACITOR 0.1uF 16V K
C208 HU-001060250 C CAPACITOR 0.1uF 16V K
C209 HU-001060250 C CAPACITOR 0.1uF 16V K
C210 HU-001060250 C CAPACITOR 0.1uF 16V K
C211 HU-001060250 C CAPACITOR 0.1uF 16V K
C212 HU-001060250 C CAPACITOR 0.1uF 16V K
C213 HU-001060250 C CAPACITOR 0.1uF 16V K
C214 HU-001060250 C CAPACITOR 0.1uF 16V K
C215 HU-001060250 C CAPACITOR 0.1uF 16V K
C216 HU-001060288 C CAPACITOR 1uF 25V
C217 HU-001060288 C CAPACITOR 1uF 25V
C218 HU-001060288 C CAPACITOR 1uF 25V
C219 HU-001060288 C CAPACITOR 1uF 25V
C220 HU-001071210 E CAPACITOR 47uF 25V
C221 HU-001060318 C CAPACITOR 0.1uF 50V
C233 HU-001060219 C CAPACITOR 1000pF 50V K
C234 HU-001060219 C CAPACITOR 1000pF 50V K
C235 HU-001060236 C CAPACITOR 10uF 25V
C236 HU-001060219 C CAPACITOR 1000pF 50V K
 Ref No. Part No. Part Name Description Local
