INSTALLATION
Front panel
REAR Connections
SIDE Connections
1: Remote control sensor.
2: Indicator LED: RED STANDBY.
3: Key board
3
2
1
≤8m
Bottom
The keyboard is located at the bottom left near the right side of signal indicator.
KEYBOARD
-5-
A ll the terminals are(from left to right): OPTICAL, VIDEO INPUT, AUDIO INPUT.
VIDEO L ROPTICA L
All the terminals are (from left to right):
HDMI1(ARC), HDMI2, HDMI3, Headphone, YPbPr, USB, RF.
HDMI1(ARC) HDMI2 HDMI3
HEADPHONE
USB
RF
YPbPr
TV Status Press
Power off
Power on
Press to power on.
-Short press to call source, then press again to choose the one you want,
it will automatically jump to the channel you select in a few seconds.
-Long press to power off.
