DSP board
Block No. [0][4][0][0]
CN301 QGB2510K1-14 CONNECTOR B-B (1-14)
CN302 QGB2510K1-14 CONNECTOR B-B (1-14)
CN492 QGB2510K1-04 CONNECTOR B-B (1-4)
CN501 QGB2510K1-07 CONNECTOR B-B (1-7)
CN801 QGB2510K1-14 CONNECTOR B-B (1-14)
CN802 QGB2510K1-14 CONNECTOR B-B (1-14)
CN901 QGB2510K1-14 CONNECTOR B-B (1-14)
EP1 E409182-001SM GRAND TERMINAL
EP201 QNZ0136-001Z EARTH PLATE
FC211 QNG0020-001Z FUSE CLIP
FC212 QNG0020-001Z FUSE CLIP
FC221 QNG0020-001Z FUSE CLIP
FC222 QNG0020-001Z FUSE CLIP
FC231 QNG0020-001Z FUSE CLIP
FC232 QNG0020-001Z FUSE CLIP
FW201 QUM217-14Z4Z4 PARA RIBON WIRE
FW251 QUM213-08DGZ4 PARA RIBON WIRE
J501 QNN0011-001 PIN JACK
J502 QNN0011-001 PIN JACK
J521 QNS0073-001 JACK
J591 QNS0073-001 JACK
PW101 QUB112-14PPPP SIN TWIST WIRE
PW102 QUB116-16PPPP PIN WIRE
PW103 QUB112-34PPPP SIN TWIST WIRE
PW104 QUB111-34PPPP SIN TWIST WIRE
PW105 QUB116-26PPPP SIN TWIST WIRE
 RY202 QSK0142-001 RELAY
 RY203 QSK0109-001 RELAY
TA201 QNZ0079-001Z TAB
TA202 QNZ0079-001Z TAB
 TH301 QAD0012-202 THERMISTOR 2k Ω L
 TH302 QAD0012-202 THERMISTOR 2k Ω L
 TH801 QAD0012-202 THERMISTOR 2k Ω L
 TH802 QAD0012-202 THERMISTOR 2k Ω L
 TH901 QAD0012-202 THERMISTOR 2k Ω L
 Symbol No. Part No. Part Name Description Local
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC615 NJM4565M-WE IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC661 DSPA56370AF IC
IC662 SN74LVC1GU04K-X IC
IC667 CS42518-CQZ-C-X IC(DIGITAL)
IC671 UPD784217AGC257 IC(FLASH MICOM)
IC672 SN74AHCT1G32K-X IC
IC673 SN74LVC1G04K-X IC
IC691 BA3259HFP-W IC
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SD601A/RS/-X TRANSISTOR
Q2142 2SD601A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SD601A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2701 UN2214-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q2702 UN2214-X TRANSISTOR
Q2703 UN2214-X TRANSISTOR
Q2704 UN2114-X TRANSISTOR
Q2705 UN2114-X TRANSISTOR
Q2706 UN2114-X TRANSISTOR
Q2708 UN2114-X TRANSISTOR
Q2709 UN2114-X TRANSISTOR
Q2710 UN2214-X TRANSISTOR
C2001 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2002 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 QETN1AM-476Z E CAPACITOR 47uF 10V M
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2102 NCB31HK-332X C CAPACITOR 3300pF 50V K
C2109 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2110 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2113 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2114 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2115 NCB31HK-822X C CAPACITOR 8200pF 50V K
C2116 NCB31HK-822X C CAPACITOR 8200pF 50V K
C2129 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2132 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2133 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2134 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2139 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2140 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2143 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2144 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2149 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2150 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2181 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2182 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2183 NCB31HK-681X C CAPACITOR 680pF 50V K
C2184 NCB31HK-681X C CAPACITOR 680pF 50V K
C2185 NCB31HK-681X C CAPACITOR 680pF 50V K
C2186 NCB31HK-681X C CAPACITOR 680pF 50V K
C2187 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2188 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2201 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2202 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2209 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2210 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2229 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2230 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2241 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2242 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2243 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2244 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2245 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2246 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2249 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2250 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2281 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2282 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2283 NCB31HK-471X C CAPACITOR 470pF 50V K
C2284 NCB31HK-471X C CAPACITOR 470pF 50V K
C2285 NCB31HK-471X C CAPACITOR 470pF 50V K
C2286 NCB31HK-471X C CAPACITOR 470pF 50V K
C2287 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2288 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2301 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2309 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2323 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2325 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2341 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
 Symbol No. Part No. Part Name Description Local
