JVC SP-DW103 Service Manual

SP-DW103
3-6
Electrical parts list
Main board
Block No. [0][1][0][0]

Symbol
No.
Part No. Part Name Description Local
IC101 BA15218F-XE IC
Dual operational
amplifier
IC102 BA15218F-XE IC
Dual operational
amplifier
IC103 BA15218F-XE IC
Dual operational
amplifier
IC104 BA15218F-XE IC
Dual operational
amplifier
IC501 BA15218F-XE IC
Dual operational
amplifier
IC502 NJM311M-XE IC
IC503 TC74HC00AF-W IC
IC504 TC74HC14AF-X IC
IC505 BU4584BF-X IC
IC506 IR2113S-X GATE DRIVER
IC571 TC74HC14AF-X IC
IC591 NJM78L05A-T IC
IC592 AN79L05-T IC
 IC951 STR-F6676 IC
Q1001 2SC2412K/RS/-X TRANSISTOR
Q1002 2SC2412K/RS/-X TRANSISTOR
Q1003 2SC2412K/RS/-X TRANSISTOR
Q1004 2SA1037AK/RS/-X TRANSISTOR
Q1005 2SD2114K/VW/-X TRANSISTOR
Q1006 2SA1037AK/RS/-X TRANSISTOR
Q1007 2SC2412K/RS/-X TRANSISTOR
Q5001 2SA1037AK/RS/-X TRANSISTOR
Q5002 2SC2412K/RS/-X TRANSISTOR
Q5003 2SA1037AK/RS/-X TRANSISTOR
Q5004 2SC4452/3-4/-X TRANSISTOR
Q5005 2SA1514K/RS/-X TRANSISTOR
Q5006 IRFI540N FET
Q5007 IRFI540N FET
Q5706 2SC2412K/RS/-X TRANSISTOR
Q5707 2SA1037AK/RS/-X TRANSISTOR
Q5708 KRC104S-X TRANSISTOR
Q5709 2SC2412K/RS/-X TRANSISTOR
Q5710 2SA1037AK/RS/-X TRANSISTOR
Q5711 2SC2412K/RS/-X TRANSISTOR
Q5712 KRA104S-X DIGI TRANSISTOR
Q5713 2SK303/3-4/-X FET
Q5714 DTC115EKA-X DIGI TRANSISTOR
Q5715 KRA104S-X DIGI TRANSISTOR
Q5716 KRC104S-X DIGI TRANSISTOR
Q5717 DTC115EKA-X DIGI TRANSISTOR
Q5718 DTC115EKA-X DIGI TRANSISTOR
Q5719 KRC104S-X DIGI TRANSISTOR
Q5720 KRA104S-X DIGI TRANSISTOR
Q5721 KRC104S-X TRANSISTOR
Q5722 DTC144TKA-X TRANSISTOR
Q5723 2SK303/3-4/-X FET
Q5901 2SD2395/EF/ TRANSISTOR
Q5902 2SA1037AK/RS/-X TRANSISTOR
Q5903 2SC2412K/RS/-X TRANSISTOR
Q5904 2SC2412K/RS/-X TRANSISTOR
Q5905 2SA1037AK/RS/-X TRANSISTOR
Q9504 2SC2412K/RS/-X TRANSISTOR
Q9508 2SA1514K/RS/-X TRANSISTOR
Q9509 2SA1514K/RS/-X TRANSISTOR
Q9510 2SC2412K/RS/-X TRANSISTOR
D1001 1SS133-T2 SI DIODE
D1002 1SS133-T2 SI DIODE
D1003 1SS133-T2 SI DIODE
D5001 1SS133-T2 SI DIODE
D5002 1SS133-T2 SI DIODE
D5003 1SS133-T2 SI DIODE
D5004 1SS133-T2 SI DIODE
D5005 1SS133-T2 SI DIODE
D5006 1SS133-T2 SI DIODE
D5007 MTZJ16B-T2 Z DIODE
D5008 M1FL20U-X FR DIODE
D5009 MTZJ18B-T2 Z DIODE
D5010 MTZJ18B-T2 Z DIODE
D5011 M1FL20U-X FR DIODE
D5012 M1FL20U-X FR DIODE
D5013 1SS355-X SI DIODE
D5703 1SS133-T2 SI DIODE
D5704 1SS355-X SI DIODE
D5705 1SS355-X SI DIODE
D5706 1SS355-X SI DIODE
D5707 1SS355-X SI DIODE
D5708 MA3200/H/-X Z DIODE
D5709 MA3200/H/-X Z DIODE
D5710 1SS355-X SI DIODE
D5711 1SS355-X SI DIODE
D5712 MA3300/L/-X Z DIODE
D5713 MA3300/L/-X Z DIODE
D5714 1SS355-X SI DIODE
D5715 1SS355-X SI DIODE
D5716 1SS133-T2 SI DIODE
D5717 1SS355-X SI DIODE
D5718 1SS355-X SI DIODE
D5901 MTZJ16B-T2 Z DIODE
D5902 MTZJ18B-T2 Z DIODE
D5903 MTZJ15A-T2 Z DIODE
D5904 MTZJ15A-T2 Z DIODE
D5905 MTZJ6.8B-T2 Z DIODE
D5906 MTZJ6.8B-T2 Z DIODE
D5907 MTZJ16B-T2 Z DIODE
D5908 MTZJ16B-T2 Z DIODE
D5909 RB160L-40-X SB DIODE
D5910 RB160L-40-X SB DIODE
D5911 1SS355-X SI DIODE
D5912 1SS355-X SI DIODE
D9001 RBV-606 BRIDGE DIODE
D9501 AW04-T2 SB DIODE
D9502 AG01Z-T2 DIODE
D9503 AG01Z-T2 DIODE
D9504 MTZJ20B-T2 Z DIODE
D9505 MTZJ20B-T2 Z DIODE
D9506 AG01Z-T2 DIODE
D9507 SARS03 SI DIODE
 D9509 FML-G22S SI DIODE
 D9510 FML-G22S SI DIODE
D9511 MTZJ15A-T2 Z DIODE
D9512 MTZJ15A-T2 Z DIODE
 PC951 PC123Y22 PHOTO COUPLER
C1001 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1002 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1003 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1004 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1005 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1006 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1007 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1008 QERF1CM-107Z E CAPACITOR 100uF 16V M
C1009 QERF1CM-107Z E CAPACITOR 100uF 16V M
C1010 QFN31HJ-104Z M CAPACITOR 0.1uF 50V J
C1011 QFN31HJ-104Z M CAPACITOR 0.1uF 50V J
C1012 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1013 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1014 QFN31HJ-563Z M CAPACITOR 0.056uF 50V J
C1015 QFVJ1HJ-224Z MF CAPACITOR 0.22uF 50V J
C1016 QTE1V06-106Z E CAPACITOR 10uF 35V
C1017 QFN31HJ-683Z M CAPACITOR 0.068uF 50V J
C1018 QFN31HJ-473Z M CAPACITOR 0.047uF 50V J
C1019 QTE1V06-106Z E CAPACITOR 10uF 35V
C1020 NCB31HK-332X C CAPACITOR 3300pF 50V K
C1021 QTE1C06-476Z E CAPACITOR 47uF 16V
C1022 QTE1C06-476Z E CAPACITOR 47uF 16V
C1023 QERF1HM-105Z E CAPACITOR 1uF 50V M
C1025 NCS31HJ-151X C CAPACITOR 150pF 50V J
C1026 NCS31HJ-151X C CAPACITOR 150pF 50V J
C1027 NCB31HK-103X C CAPACITOR 0.01uF 50V K

Symbol
No.
Part No. Part Name Description Local

JVC SP-DW103 Specifications

General

Brand	JVC
Model	SP-DW103
Category	Subwoofer
Language	English
