11
Parts Identification
Become familiar with the buttons and controls on the unit before use. Refer to the pages in parentheses for details.
Center unit ———————————————————————————————————————
1 2 3
4
5678p
1 button and STANDBY
lamp (16)
2 Remote sensor (10)
3 Disc tray (22)
4 DVD CONTROL buttons
(22~24)
5 VOLUME +/ – button (16)
6 DSP MODE/INPUT ATT.
(19, 20, 21)
7 SURROUND/SOURCE
NAME (17, 21)
8 SOURCE (17)
9 Display window
p Audio channel lamp (19)
9
Display window
1 2 3
4 5
6
789
Front panel
1 Decord mode indicator (18)
2 Radio indicator (36)
3 Multi-information window
Display time and status information.
4 Time selection indicator (34)
5 PROGRAM indicator (34)
Powered sub woofer —————————————————————————————————————
6 RESUME indicator (24)
7 Radio reception mode indicator (37)
8 ATT. indicator (19)
9 DSP indicator (20)
1
2
1 POWER ON lamp (16)
2 Speaker
To Next Page
