2
Getting Started
Important cautions
Installation of the unit
Select a place which is level, dry and neither too hot nor too cold
between 5°C and 35°C (41°F and 95°F).
Leave sufficient distance between the unit and the TV.
Do not use the unit in a place subject to vibrations.
Power cord
Do not handle the power cord with wet hands!
A small amount of power (3 W) is always consumed while the
power cord is connected to the wall outlet.
When unplugging the unit from the wall outlet, always pull the
plug, not the power cord.
To prevent malfunction of the unit
There are no user-serviceable parts inside. If anything goes
wrong, unplug the power cord and consult your dealer.
Do not insert any metallic object into the unit.
Do not use any non-standard shape disc available on the market,
because it may damage the unit.
Do not use a disc with tape, seals, or paste on it, because damage
to the unit may result.
Note about copyright laws
Please check the copyright laws in your country before recording
from DVD VIDEO, Audio CD, Video CD, and SVCD discs.
Recording of copyrighted material may infringe copyright laws.
Note about the copyguard system
The DVD VIDEO disc is protected by the copyguard system.
When you connect the unit to your VCR directly, the coryguard
system activates and the picture may not be played back correctly.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
Safety precautions
Avoid moisture, water and dust
Do not place your unit in moist or dusty places.
Avoid high temperatures
Do not expose the unit to direct sunlight or place it near a heating
device.
When you’re away
When away on travel or otherwise for an extended period of time,
remove the plug from the wall outlet.
Do not block the vents
Blocking the vents may damage the unit.
Care of the cabinet
When cleaning the unit, use a soft cloth and follow the relevant
instructions on the use of chemically-coated cloths. Do not use
benzene, thinner or other organic solvents and disinfectants. These
may cause deformation or discoloring.
If water gets inside the unit
Turn off the power switch and remove the plug from the wall outlet,
then call the store where you made your purchase. Using the unit in
this state may cause a fire or electrical shock.
Checking the supplied accessories
Check to be sure you have all of the following items, which are
supplied with the unit.
The number in the parentheses indicates quantity of the pieces
supplied.
Primary
remote
control (1)
Secondary
remote
control (1)
Batteries (4)
AM Loop
Antenna (1)
FM Antenna (1)
AC Power Cord (1)
Video Cable (1)
Compulink Cord (1)
System Cable (1)
Speaker Cord 6 m (19.7 ft)
(3)
Speaker Cord 15 m (49.2 ft)
(2)
Satellite speaker
wall bracket (4)
Screws (4)
Non-slip rubbers (3)
