REAR VIEW
S VIDEO
S VIDEO
ANTENNA IN
ANTENNA OUT
VHF/UHF
VIDEO
VIDEO
AUDIO
RL
RL
IN
L-1
CABLE
BOX
AUDIO
A
ANTENNA IN Connector
墌
pg. 12
B
S VIDEO IN Connector
墌
pg. 56, 58
C
VIDEO/AUDIO IN Connectors
墌
pg. 56, 58
D
S VIDEO OUT Connectors
墌
pg. 13, 58
E
VIDEO/AUDIO OUT Connectors
墌
pg. 58
F
AC Power Cord
墌
pg. 12
G
ANTENNA OUT Connector
墌
pg. 12
H
CABLE BOX Connector
墌
pg. 20, 23
I
Cooling fan
●
This prevents the temperature from rising inside the VCR.
Do not remove it.
●
Install the VCR so as not to block the area around the fan.
●
The fan may be activated even if the VCR is turned off.
