MAIN BOARD ASSEMBLY <01>
!
REF. MODEL
GR-SXM48EG-X GR-SXM28EG-F GR-SXM58EG-X GR-SXM58EG-Y GR-SXM58EG-Z GR-SXM780A
NO. ITEM
PW1 MAIN BOARD ASSY YB10356EB1-01 YB10356EH1-01 YB10356EC1-01 YB10356EJ1-01
IC101 IC(MICRO C ROM) UPD703039-038 UPD703039-039
IC105 IC(DIGITAL) ——TC7S66FU
IC1801 IR DETECT UNIT —————PIC-26043S
IC4002 IC Z4C2973-32-X — Z4C2973-32-X
IC8001 IC ——MAX3221CAE
Q6306 MOS FET SSM3K02F — SSM3K02F
Q6621 PAIR TRANSISTOR —————HN1C01FU/G/-X
Q6622 TRANSISTOR —————2SA1577/QR/-X
D8001 ZENER DIODE ——EMZ6.8N
R182 MG RESISTOR ——NRSA63J-105X
R4013 MG RESISTOR NRSA63J-102X — NRSA63J-102X
R6306 MG RESISTOR NRS12BK-R47W — NRS12BK-R47W
R6307 MG RESISTOR NRSA63J-104X — NRSA63J-0R0X
R6622 CMF RESISTOR —————NRVA63D-104X
R6623 CMF RESISTOR —————NRVA63D-473X
R6624 MG RESISTOR —————NRSA63J-273X
R6625 MG RESISTOR —————NRSA63J-822X
R6626 CMF RESISTOR —————NRVA63D-273X
R6627 CMF RESISTOR —————NRVA63D-183X
R8001 MG RESISTOR ——NRSA63J-331X
R8002 MG RESISTOR ——NRSA63J-0R0X
R8003 MG RESISTOR ——NRSA63J-0R0X
C4024 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C4044 CAPACITOR NCB30JK-105X — NCB30JK-105X
C6307 E CAPACITOR NEA71CM-106X — NEA71CM-106X
C6622 CAPACITOR —————NCB21CK-105X
C8001 CAPACITOR ——NCF31EZ-104X
C8002 CAPACITOR ——NCF31EZ-104X
C8003 CAPACITOR ——NCF31EZ-104X
C8004 CAPACITOR ——NCF31EZ-104X
C8005 T CAPACITOR ——NBE20JM-106X
C8006 CAPACITOR ——NCF31EZ-104X
L501 MG RESISTOR ——NRSA63J-0R0X
L8001 COIL ——NQL365K-220X
CN6 CONNECTOR QGA1201C2-02X — QGA1201C2-02X
MONITOR BOARD ASSEMBLY <07>
!
REF. MODEL
GR-SXM48EG-X GR-SXM28EG-F GR-SXM58EG-X GR-SXM58EG-Y GR-SXM58EG-Z GR-SXM780A
NO. ITEM
PW MONITOR BOARD ASSY YB20913A YB20913B
IC7603 IC SN74AHC1G04K —
Q7607 TRANSISTOR DTC144EE —
R7602 MG RESISTOR NRSA63D-752X NRSA63D-432X
R7607 MG RESISTOR NRSA63D-822X NRSA63D-153X
R7637 MG RESISTOR NRSA63J-223X NRSA63J-682X
R7640 MG RESISTOR NRSA02J-182X NRSA02J-122X
R7641 MG RESISTOR NRSA02J-331X NRSA02J-821X
R7642 MG RESISTOR —————NRSA63J-0R0X
R7643 MG RESISTOR —————NRSA63J-123X
R7644 MG RESISTOR —————NRSA63J-123X
R7645 MG RESISTOR NRSA63J-682X NRSA63J-123X
R7646 MG RESISTOR NRSA63J-392X NRSA63J-222X
R7647 MG RESISTOR —————NRSA63J-0R0X
R7648 MG RESISTOR NRSA63J-103X —
R7649 MG RESISTOR —————NRSA63J-333X
R7650 MG RESISTOR NRSA63J-103X —
C7623 CAPACITOR NCB31EK-682X —
C7627 CAPACITOR NCB31EK-103X —
C7630 CAPACITOR —————NCB31EK-103X
L7603 COIL —————NQL38DK-220X
L7604 COIL NQL38DK-220X
—
Notes : Mark is same as left.
Mark — is not used.
