Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
 IC300 LA4663 POWER IC
IC301 HA17558A IC
IC302 LC75342 IC
IC601 AN22000A-W IC
 IC602 LA6541-X IC
IC603 MN662748RPMFA IC
IC604 KIA78S05P-T IC
Q601 KTA1271/OY/-T TRANSISTOR
Q1150 2SC3576-JVC-T TRANSISTOR
Q1400 2SC2785/FE/-T TRANSISTOR
Q2150 2SC3576-JVC-T TRANSISTOR
Q2400 2SC2785/FE/-T TRANSISTOR
Q3110 2SC3576-JVC-T TRANSISTOR
Q3111 KRC111M-T TRANSISTOR
Q3150 KRA101M-T TRANSISTOR
Q3151 KRC102M-T DIGI TRANSISTOR
 Q9001 KTA1046/Y/ TRANSISTOR
Q9002 2SC2785/FE/-T TRANSISTOR
Q9003 2SA1175/FE/-T TRANSISTOR
Q9004 KRC114M-T TRANSISTOR
Q9005 KRA114M-T TRANSISTOR
Q9006 2SC2785/FE/-T TRANSISTOR
Q9070 2SC3576-JVC-T TRANSISTOR
Q9201 KTB772/Y/ TRANSISTOR
Q9202 2SC2785/FE/-T TRANSISTOR
Q9301 KTA1267/YG/-T TRANSISTOR
Q9302 2SC2785/FE/-T TRANSISTOR
D661 1SS133-T2 DIODE
D662 1SS133-T2 DIODE
 D901 6A10E2 SI DIODE
 D902 6A10E2 SI DIODE
 D903 6A10E2 SI DIODE
 D904 6A10E2 SI DIODE
 D905 6A10E2 SI DIODE
D3150 MTZJ5.1C-T2 Z DIODE
D3151 1SS133-T2 DIODE
D3153 1SS133-T2 DIODE
D3400 1SS133-T2 DIODE
D3401 1SS133-T2 DIODE
D3402 1SS133-T2 DIODE
D3403 1SS133-T2 DIODE
D3504 1SS133-T2 DIODE
D3505 1SS133-T2 DIODE
D9001 1SS133-T2 DIODE
D9002 MTZJ8.2C-T2 Z DIODE
D9020 MTZJ5.6C-T2 Z DIODE
D9201 MTZJ4.3B-T2 Z DIODE
D9302 1SS133-T2 DIODE
D9303 1SS133-T2 DIODE
D9501 1SS133-T2 DIODE
D9502 1N4003S-T5 SI DIODE
C602 QCSB1HJ-560Y C CAPACITOR 56pF 50V J
C604 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C605 QETN1EM-106Z E CAPACITOR 10uF 25V M
C606 QFVF1HJ-823Z MF CAPACITOR 0.082uF 50V J
C608 QETN1HM-105Z E CAPACITOR 1uF 50V M
C610 QFVF1HJ-393Z MF CAPACITOR 0.039uF 50V J
C611 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C612 QDXB1CM-272Y C CAPACITOR 2700pF 16V M
C613 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C614 QCZ0313-105Z C CAPACITOR 1uF 25V Z
C615 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C616 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C617 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C618 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C619 QCBB1HK-561Y C CAPACITOR 560pF 50V K
C620 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C622 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C623 QFVF1HJ-563Z MF CAPACITOR 0.056uF 50V J
C624 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C625 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C628 QDX31EM-473Z C CAPACITOR 0.047uF 25V M
C629 QETN1AM-227Z E CAPACITOR 220uF 10V M
C631 QETN1AM-477Z E CAPACITOR 470uF 10V M
C632 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C633 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C634 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C635 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C636 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C638 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C641 QCZ0313-105Z C CAPACITOR 1uF 25V Z
C642 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C643 QEQ61HM-225Z E CAPACITOR 2.2uF 50V M
C644 QFN31HJ-153Z M CAPACITOR 0.015uF 50V J
C645 QEQ61HM-225Z E CAPACITOR 2.2uF 50V M
C651 QCSB1HJ-120Y C CAPACITOR 12pF 50V J
C652 QCSB1HJ-150Y C CAPACITOR 15pF 50V J
C653 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C655 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C661 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C662 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C663 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C664 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C665 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C668 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C669 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C670 QETN1AM-107Z E CAPACITOR 100uF 10V M
C671 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C672 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C673 QETN1AM-477Z E CAPACITOR 470uF 10V M
C674 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C675 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C676 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C677 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C691 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C692 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C693 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C694 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C695 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C901 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C902 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C903 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C904 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C1100 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1101 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1102 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C1103 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C1104 QTE1V06-106Z E CAPACITOR 10uF 35V
C1105 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C1300 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1301 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1302 QTE1V06-106Z E CAPACITOR 10uF 35V
C1303 QFVJ1HJ-334Z MF CAPACITOR 0.33uF 50V J
C1502 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1503 QTE1V06-106Z E CAPACITOR 10uF 35V
C1504 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1505 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1506 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C1507 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1508 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1510 QETN1EM-106Z E CAPACITOR 10uF 25V M
C1600 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2100 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2101 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C2102 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C2103 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C2104 QTE1V06-106Z E CAPACITOR 10uF 35V
C2105 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2300 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C2301 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C2302 QTE1V06-106Z E CAPACITOR 10uF 35V
C2303 QFVJ1HJ-334Z MF CAPACITOR 0.33uF 50V J
C2502 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
 Symbol No. Part No. Part Name Description Local
