Page 7
STANDBY/ON
STANDBY
BASIC OPERATIONS
Basic functions for disc
playback
Main unit
Loading a disc in the disc tray
Use the 0 OPEN/CLOSE button to open and close the disc tray.
1. Open the disc tray by pressing the 0 OPEN/CLOSE button.
2. Place a disc on the disc tray according to the groove with its
label side up.
3. Close the disc tray by pressing the 0 OPEN/CLOSE button.
Note
÷
When loading a disc in the disc tray, be sure to put the disc according
to the groove. Otherwise, the disc will be damaged when the disc
tray is closed, and the disc cannot be removed from the unit.
OPEN/
CLOSE
Main unit
Good
No Good
Remote control operation (XL-V230BK Only)
Point the remote control unit towards the remote sensor and operate it
steadily and carefully. The remote control unit can be used within a
range of about 7 meters (23 feet) from the remote sensor, and at angles
of up to about 30 degrees.
Turning on the power of this unit
Press the (STANDBY/ON) button to turn on this unit. The
STANDBY indicator is turned off and the display is turned on.
Press again to turn the power off and activate the standby mode. The
STANDBY indicator is lit.
The power is automatically turned on also by;
÷ Pressing the 0 OPEN/CLOSE button.
÷ Pressing the 3 button on the remote control unit or the 3/8 PLAY/
PAUSE button on the main unit.
Notes
÷
A small amount of power (4 watts) is consumed even in the standby
mode.
÷
To turn the power off completely, disconnect the power cord from the
wall outlet.
OPEN/CLOSE
0
Compact disc
Disc tray
Main unit
Remote control unit
(XL-V230BK ONLY)
Remote control unit
(XL-V230BK ONLY)
XL-V130BK [BS] EN 97.3.7, 4:11 PM7
