9.800-103.0 - M • Karcher HDS 615-617
23
PRESSURE WASHER
OPERATOR’S MAN U AL
EXPLODED VIEW PARTS LIST
GHF, w/Strainer 1
ITEM PART NO. DESCRIPTION QTY
72 8.706-600.0 Box, Battery, M-100 1
73 9.803-532.0 Isolator, 5/16" Thread,
Female x Female, 1" x 1" 7
74 9.803-504.0 Bracket, Battery
1
75 9.803-277.0 Screw, 5/16" x 1/2"
Whiz Loc 4
76 9.802-756.0 Screw, 5/16" x 1"
Whiz Loc 4
77 9.803-505.0 Bracket, Mount 1
78
9.803-560.0 Screw, 3/8" x 2" 4
79 9.802-756.0 Screw, 5/16" x 1"
Whiz Loc 2
80 9.802-776.0 Nut, 5/16" ESNA, NC 2
81 8.751-057.0 Cap, 14" w/Fuel Gauge,
Gas, Red 1
82 9.803-535.0 Cap, 14" w/Fuel Gauge,
Gas, Black 1
83 9.802-832.0 Bolt, 5/16" x 2-3/4"
Whiz Loc 2
84 5.363-360.0 Copper Disk 2
85 9.802-201.0 Clamp, Screw, #6 1
86 9.802-260.0 Hose, 5/8" Push-On 60”
87 9.803-519.0 Plate, Belt Guard 1
88 9.803-506.0 Guard, Engine Pulley 1
89 9.802-512.0 Cable, Tie, 45" 4
90 9.802-053.0 Bushing, Rubber, Nitrite 3
91 9.803-531.0 Elbow, 1/4" H x STD
Pipe,90° 2
92 9.802-054.0 Elbow, Fuel Tank, Zinc 1
93 9.803-541.0 Screw, 5/16-18 x 1/2"
CS SOC 4
94 9.803-542.0 Washer, 5/16" Star 4
95 9.802-813.0 Washer, 5/16" Lock 4
96 8.718-618.0 Bolt, 5/16" x 3/4" NC
Grade 5 4
97 8.932-965.0 Label, Warning -
Exposed Pulleys 2
98 9.800-006.0 Label, Hot - Caliente 1
99 8.900-282.0 Label, RPM Factory Set 2
100
9.802-764.0 Screw, 10/32" x 3/4" Hex 2
101
9.802-779.0 Nut, 3/8" ESNA (615.0,
617.0) 4
9.802-776.0 Nut, 5/16" ESNA (616.0) 4
102 9.802-807.0 Washer,
3/8"
SAE,
Flat (Honda) 8
8.718-980.0 Washer, 5/16" SAE,
Flat (Vanguard) 8
103 9.802-764.0 Screw, 10/32" x 3/4" Hex 2
104 8.911-537.0 Rail, Cage w/Holes 1
