12
Operations
Technical Specifications
NOTE: Always use a pad, which has been designed for electric ultra high speed burnishing of at least
2000 rpm.
ITEM DIMENSION/CAPACITY
Construction Molded UL - recognized PE chassis, tubular steel self adjusting
handle with die cast aluminum handle housing.
Motor 1.5 hp
Transmission Direct drive from motor shaft.
Pad speed 2000 rpm
Electrical system:
LB2000I 230 volts, 50Hz
LB2000 115 volts, 60Hz
Cable
75’ [22.9 m]
Switches Dual levers with safety lock.
Pad Holder 20” diameter [50.8 cm] flexible disc
Wheels Four 5” diameter [12.7 cm], 1.25” [3.2 cm] wide, non-marking tread.
Handle 1.5” diameter [3.8 cm] tubular steel, self adjusting handle
consistently maintains full contact with the floor, and easy to use
thumb activated safety lock.
Dimensions (L x W x H) 32” [81.3 cm] X 23.9” [60.2 cm] X 48.4” [122.9 cm]
Pad size (See note) 20” diameter x 1” thick
86387310 Operators Manual - High Speed Burnisher (2000 Series)
