Kärcher HD 10/25-4 S User Manual

– 10
Technical specifications
Main Supply
Voltage V 440...460
Current type Hz 3~ 60
Connected load HP 10
Protection (slow, char. C) A 16
Type of protection IPX5
Maximum allowed net impedance Ohm (0,145+j0,0
90)
Extension cable 10 m mm
2
2.5
Extension cord 30 m mm
2
4
Water connection
Max. feed temperature °F 140
Min. feed volume gpm 5.3
Suck height from open container (20 °C) m 0.5
Max. feed pressure psi 145
Performance data
Working pressure psi 435...3190
Nozzle size 055
Max. operating over-pressure psi 3480
Flow rate gpm 2.2...4.5
Detergent suck in gpm 0...0.3
Max. recoil force of trigger gun N 62
Values determined as per EN 60335-2-79
Hand-arm vibration value
Hand spray gun m/s
2
<2.5
Spray lance m/s
2
<2.5
Uncertainty K m/s
2
0.3
Sound pressure level L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 87
Fuel
Amount of oil l 1.2
Oil grade SAE 90
Dimensions and weights
Length mm 560
Width mm 500
Height mm 1090
Typical operating weight kg 60
Content detergent tank l 6
12 EN

Kärcher HD 10/25-4 S Specifications

General

Connected load	7500 W
AC input voltage	220 V
Number of phases	3
AC input frequency	60 Hz
Maximum pressure	209 bar
Working pressure (max)	190 bar
Working pressure (min)	30 bar

Weight and Dimensions

Depth	500 mm
Width	560 mm
Height	1090 mm
Weight	62000 g
