Kärcher HD 10/25-4 S User Manual

– 7
 Open the hand spray gun.
The appliance will switch on again.
On opening the hand-spray gun, the device
starts within the readiness period. The indi-
cator lamp glows green.
The readiness period is over if the hand-
spray gun remains closed for 30 minutes.
The indicator lamp blinks green.
 Set the appliance switch to "0".
 Wait for a while.
 Set the appliance switch to "I".
Customer Service can switch the device to
continuous operations.
 Shut off water supply.
 Open the hand spray gun.
 Switch on the pump with the power
switch and allow to run for about 5-10
seconds.
 Close the hand spray gun.
 Set the appliance switch to "0/OFF“.
 Pull main plug out of socket with dry
hands only.
 Remove water connection.
 Activate hand spray gun until device is
pressure less.
 Secure the trigger gun. To do so, push
the safety catch towards the front.
 DANGER
Danger of scalding on account of hot water.
The water remaining in the switched off de-
vice can get heated up. When you remove
the hose from the water inlet, the heated
water can spray out and cause scalding. Do
not remove the hose before the device has
cooled down.
 Insert the hand-spray gun in the holder.
 Wind up the high-pressure hose and
hang it over the hose storage.
or
Wind up the high-pressure hose on the
hose drum. Push in the handle of the
crank to block the hose drum.
 Wind the connection cable around the
cable holder.
ATTENTION
Frost will destroy the not completely water
drained device.
Store the appliance in a frost free area.
 Emptying the detergent tank (see "Care
and Maintenance/ as required").
 Drain water.
 Pump in conventional frost protection
agents through the appliance.
Note:
Use normal glycol-based anti-freezing
agents for automobiles.
Observe handling instructions of the anti-
freeze agent manufacturer.
 Operate device for max. 1 minute until
the pump and conduits are empty.
몇 CAUTION
Risk of personal injury or damage! Mind the
weight of the appliance during transport.
ATTENTION
Protect the trigger from damage during
transport.
 Pull the device behind you at the handle
for transporting it over longer distances.
 Empty the detergent tank before trans-
porting in horizontal position.

When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
몇 CAUTION
Risk of personal injury or damage! Consider
the weight of the appliance when storing it.
This appliance must only be stored in inte-
rior rooms.
Operational readiness period
Reset readiness period
Turn off the appliance
Storing the Appliance
Frost protection
If you cannot store it in a frost-free
place:
Transport
Storage
9EN

Kärcher HD 10/25-4 S Specifications

General

Connected load	7500 W
AC input voltage	220 V
Number of phases	3
AC input frequency	60 Hz
Maximum pressure	209 bar
Working pressure (max)	190 bar
Working pressure (min)	30 bar

Weight and Dimensions

Depth	500 mm
Width	560 mm
Height	1090 mm
Weight	62000 g
