16
HDS 895
GB
3. Technical Data
1.027-901 1.027-903 GB 1.027-902
Power connection
Voltage 400 V 420 V 230 V
Type of current 3 ~ 50 Hz 3 ~ 50 Hz 3 ~ 60 Hz
Connected load 6,4 kW 6,4 kW 7,6 kW
Mains fuse (slow) 16 A 16 A 30 A
Water connection
Supply temperature (max.) 30 °C 30 °C
Supply rate (min.) 1200 l/h 1200 l/h
Suction height fom open tank
at a water temperature of 20 °C 0.5 m 0.5 m
Performance data
Operating pressure 30–170 bar 30–170 bar
Flow rate 470–1000 l/h 470–1000 l/h
Operating temperature (max.) 140/80 °C 140/80 °C
Detergent intake 0–50 l/h 0–50 l/h
Burner capacity 76 kW 77 kW
Recoil force of hand-held spray gun
at operating pressure (max.) 43 N 43 N
Sound pressure level (DIN 45 635) 76 dB(A) 76 dB(A)
Dimensions
Length 1285 mm 1285 mm
Width 690 mm 690 mm
Height 835 mm 835 mm
Weight without accessories 120 kg 120 kg
Fuel tank 25 l 25 l
Fuel EL fuel oil or diesel EL fuel oil or diesel
Detergent tank 20 l 20 l
Pump oil quantity 0.6 l 0.6 l
Pump oil type (order no. 6.288-016) Hypoid SAE 90 Hypoid SAE 90
