Kärcher K 2.300 User Manual

6 English
Screwdriver, small size (not supplied)
for connecting high pressure hose and
trigger gun.
 STEP 1:
Insert wheels into the body of the unit.
 STEP 2:
Slide the transport handle into place.
 STEP 3:
Install the supplied connector to the
unit’s water inlet.
Note: Never attach the garden hose
connector to the unit’s water inlet!
 STEP 4:
Fasten the quick connect to the high
pressure outlet.
 STEP 5:
Insert one end of the high pressure
hose into the trigger gun until it locks
audibly.
Note: Make sure the connection nip-
ple is aligned correctly. Check the
connection by pulling on the high
pressure hose.
Check the secure connection by pull-
ing on the high pressure hose.
Disconnect:
 Press the disconnect key on the trig-
ger gun and remove the high pres-
sure hose from the trigger gun.
 STEP 1:
Insert one end of the high pressure
hose tightly into the quick connect on
the unit, it will lock in audibly.
Note: Make sure the connection nip-
ple is aligned correctly. Check the
connection by pulling on the high
pressure hose.
Check the secure connection by pull-
ing on the high pressure hose.
ASSEMBLY INSTRUCTIONS
Required tools
Assembly
OPERATING
INSTRUCTIONS

Kärcher K 2.300 Specifications

General

Maximum flow rate	360 l/h
Working pressure (max)	110 bar
Maximum input water temperature	40 °C
Form factor	Upright
Hose length	4 m
Water filter	Yes
Product color	Yellow
Surface cleaner	No
Power consumption (typical)	1400 W

Weight and Dimensions

Depth	242 mm
Width	280 mm
Height	783 mm
Weight	4800 g
