Kärcher K 5 Premium User Manual

English 13
Only use original accessories and spare
parts, they ensure the safe and trouble-free
operation of the device.
For information about accessories and
spare parts, please visit www.kaerch-
er.com.
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Subject to technical changes.
Accessories and Spare Parts
Warranty
Technical specifications
Electrical connection
Voltage 220
1~ 50
V
Hz
Connected load 2,1 kW
Protection class IP X5
Protective class I
Water connection
Max. feed pressure 0,8 MPa
Max. feed temperature 40 °C
Min. feed volume 10 I/min
Max. Suction height 0,5 m
Performance data
Working pressure 12,5 MPa
Max. permissible pressure 14,5 MPa
Water flow rate 7,5 I/min
Max. flow rate 8,3 I/min
Detergent flow rate 0-0,3 I/min
Recoil force of trigger gun 20 N
Dimensions and weights
Length 349 mm
Width 426 mm
Height 878 mm
Weight, ready to operate
with accessories
15,3 kg

Kärcher K 5 Premium Specifications

General

Form factor	Upright
Hose length	8 m
Power source	Electric
Water filter	Yes
Product color	Black, Yellow
Maximum flow rate	500 l/h
Working pressure (max)	145 bar
Working pressure (min)	20 bar
Maximum input water temperature	40 °C
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Surface cleaner	-

Weight and Dimensions

Depth	349 mm
Width	426 mm
Height	878 mm
Weight	14500 g
