English 7
1 Coupling element for water connection
2 Water connection with integrated sieve
3 Appliance switch „0/OFF“ / „I/ON“
4 High pressure hose
5 Dosage regulator for detergent
6 Storage for trigger gun
7 High-pressure hose drum
8 Transport handle
9 Hand crank for hose drum
10 Storage of Plug 'n' Clean detergent bot-
tle with detergent connection
11 Storage for accessories
12 Storage hook for mains connection cable
13 Mains cable with mains plug
14 Plug 'n' Clean detergent bottle with
locking lid
15 Wheels
16 Trigger gun
17 Lock trigger gun
18 Key to detach the high pressure hose
from the trigger gun
19 Spray lance with pressure regulation
(Vario Power)
Carrying out the most common cleaning
tasks. The work pressure can be stage-
lessly regulated between "Min" and
"Max". You can add detergent when
"Mix" is selected.
In order to adjust the working pressure, re-
lease the lever of the trigger gun and turn
the spray lance to the desired position.
20 Spray lance with Dirtblaster
For strong contaminations
– Minimum diameter, 1/2 inches (13 mm).
– Minimum length 7.5 m.
Mount loose parts delivered with appliance
prior to start-up.
Illustrations on Page 14
Illustration
 Install the transport wheels.
 Attach the wheel caps.
Illustration
 Place the bottom holder into the recess-
es and push forward until it audibly
locks in.
 Insert the top holder and push down all
the way.
Illustration
 Press in the storage hook and lock it
into the top position.
Illustration
You will need the 2 included screws as well
as a Phillips screwdriver PH 2.
 Slide the transport handle into the guide
and secure it with 2 screws.
Illustration
You will need the 2 included screws as well
as a Phillips screwdriver PH 2.
 Insert both detergent hoses onto the
hose fittings.
 Install the dosage regulator and con-
nect using 2 screws.
Note: During installation you must make
sure that the tongues of the dosage regula-
tor match up with the intended recesses in
the casing.
Description of the Appliance
Additionally required
• Water supply hose
Fabric-reinforced water hose with com-
mercially available coupling.
Assembly
Install wheels
Install the storage for trigger gun
Install the storage hook for the
mains connection cable
Install the transport handle
Install the dosage regulator for
detergent

Kärcher K 5 Premium Specifications

General

Form factor	Upright
Hose length	8 m
Power source	Electric
Water filter	Yes
Product color	Black, Yellow
Maximum flow rate	500 l/h
Working pressure (max)	145 bar
Working pressure (min)	20 bar
Maximum input water temperature	40 °C
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	2100 W
Surface cleaner	-

Weight and Dimensions

Depth	349 mm
Width	426 mm
Height	878 mm
Weight	14500 g
