2260B Series User Manual
38
How to Use the Instrument
Background
The 2260B power supplies use a novel method
of configuring parameter values only using the
Voltage or Current knobs. The knobs are used
to quickly edit parameter values at 0.01, 0.1 or 1
unit steps at a time.
When the user manual says to set a value or
parameter, use the steps below.
Example
Use the Voltage knob to set a voltage of 10.05
volts.
6. Repeatedly press the Voltage knob
until the last digit is highlighted.
This will allow the voltage to be
edited in 0.01 volt steps.
7. Turn the Voltage knob till 0.05
volts is shown.
Voltage
V
A
→
V
A
8. Repeatedly press the Voltage knob until the
first digit is highlighted. This will allow the
voltage to be edited in 1 volt steps.
9. Turn the Voltage knob until 10.05 is shown.
Voltage
