Recommended hood styles are shown
here.
1
(10.2 cm)
1. Louvered hood style
2. Box hood style
The angled hood style (shown following)
is acceptable.
4"
(10.2__
,ds 'm,
See the exhaust vent length chart that
matches your hood type for the maxi-
mum vent lengths you can use.
Exhaust systems longer than specified
will:
• Shorten the life of the dryer.
• Reduce performance, resulting in longer
drying times and increased energy
usage.
3. Determine the number of elbows you
will need.
NOTE: Do not use vent runs longer
than specified in Vent Length Chart.
Install Vent System
1. (Optional) Put on safety glasses and
gloves.
2. Install exhaust hood. Use caulking com-
pound to seal exterior wall opening
around exhaust hood.
3. Connect vent to exhaust hood. Vent
must fit inside exhaust hood. Secure
vent to exhaust hood with 4 in.
(10.2 cm) clamp.
4. Run vent to dryer location. Use the
straightest path possible. See
"Determine Vent Length." Avoid 90°
rums. Use duct tape to seal all joints.
Install Leveling Legs
Excessive Weight Hazard
Use two or more people to move
and install dryer.
Failure to do so can result in back
or other injury.
1. Place two of the carton corner posts
on the floor behind the back of the
dryer. See illustration.
2. Firmly grasp the body of the dryer
(not the top or console panel).
The chart below helps you determine
your maximum vent length based on
the number of 90° turns or elbows
[rOUwill need and the type of vent
igid or flexible metal) and hood that
you will use.
Vent Length Chart
Numberof Typeof Boxor Angled
90° turns vent Louvered hoods
or elbows hoods
0 Rigidmetal 64ft(20m) 58ft(17,7m)
36ft (11m) 28ft (8.5m)
54ft (16.5m) 48ft (14.6m)
Flexible metal
1 Rigid metal
Flexible metal
2 Rigid metal
Flexible metal
3 Rigid metal
Flexible metal
4 Rigid metal
Gently lay the dryer on the cardboard
corners.
3. Examine the leveling legs. Find the
diamond marking.
31ft (9.4m) 23ft (7m) 4. Screw the legs into the leg holes by
44ft (13.4m) 38ft (11.6m) hand. Use a wrench to finish tuming
27ft (8.2m) 19ft(5.8m) the legs until the diamond marking is
35ft(1O.7m) 29ft(8.8m) no longer visible.
25ft (7.6m) 17ft (5.2m)
27ft (8.2m) 21ft (6.4m) 5, Stand the dryer up. Move it close to
its final location. Leave enough room
............................................................. ..........to connect the exhaust vent.
17
To Next Page
