2. Specifications
To avoid risk of electrical shock that can cause death or severe personal injury,
disconnect unit from power before servicing unless tests require power.
6 / 69
!
WARNING
(continued)
Model Name
111.7269****
Factory Model Name
RFP83KE*****
Sensor
Defrost(F/D-SENSOR, R/D-SENSOR,I/M-D-
SENSOR)
In Evaporator Assembly,
In Icemaker Evaporator Assembly
Freezer(F-SENSOR)
In Louver Assembly
Refrigerator(R- SENSOR)
In Multi Flow Duct Assembly
RT(“RT-SENSOR” in Wiring Diagram)
Between Top Cabinet and Top Cover Hinge
Icemaker Room Temp.(ICE DUCT-SENSOR)
In Fixture Geared Motor Assembly
Pantry Drawer Temp.(PANTRY-SENSOR)
In Multi Flow Duct Assembly
Water Flow(FLOW SENSOR)
In Valve Water Assembly
Heater
F SHEATH HTR (Freezer Evaporator)
AC120V / 250W / 57.6Ω ±5% / Sheath
R-SHEATH HTR(Refrigerator Evap.)
AC120V / 120W / 120Ω ±5% / Sheath
R I/MAKER SHEATH HTR(I/M Room Evap.)
AC120V / 40W / 360Ω ±5% / Sheath
DV HTR(Located in Mullion Bar)
DC11.5V / 5.2W / 25.4Ω ±7%
Water Tank
AC120V / 5W / 2650 ~ 3110Ω
I/CASE HTR(Located in Rear of Cabinet)
DC 12V / 5W / 28.8Ω ±8% ( No Service Part )
DISPNS HTR(Located in Dispenser Box)
DC12V / 2.5W / 57.6Ω ±8% (Cycles based on temps)
W/TUBE HTR(Located in Top of Cabinet)
DC12 / 1W / 144Ω ±8% (No Service Part)
R ICE AL PIPE HTR (Icemaker mold heater)
AC120V / 130W / 110.8Ω ±5% / Sheath (No
Service Part)
I/M BOX HTR(Located in Icemaker Room)
DC12 / 2W / 72Ω ±8% (No Service Part)
Fuse Temp (Defrost)
AC250V , 10A , 77℃
Motor
Freezer Fan(F MOTOR)
DC12V / 12038GE-12M-YU-D2
Refrigerator Fan(R MOTOR)
DC12V / 12038GE-12L-YU-D1
Condenser Fan(C MOTOR)
DC12V / ODM-001F-D2
Dispenser Ice Shut(DR ICE SHUTTER)
DC 12V / STAA125A01
Ice Crusher(GEARED MOTOR)
120V / 60Hz / ISG-3240DED
Ice Type Selector(ICE-SELECTOR)
DC12V / STAB04D01
Ice Maker Fan(I/M BOX MOTOR)
DC12V / ODM-016F-57A
Damper
DC12V / DU24-113 / 1pcs
