C-V100/V150/V300/V350
PARTS LIST
43
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas Q : Russia
indicates safety critical components.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas Q : Russia
indicates safety critical components.
- ✽ H50-2483-04 ITEM CARTON CASE MI
- ✽ H50-2484-04 ITEM CARTON CASE C
- ✽ H50-2519-04 ITEM CARTON CASE X
670 2C ✽ J02-1188-03 FOOT KPY
670 2C ✽ J02-1189-03 FOOT MICX
671 1C J19-3331-05 UNIT HOLDER
672 1C J19-3642-05 UNIT HOLDER
673 2B,1C J19-3732-04 UNIT HOLDER KPY
673 2B,1C J19-3751-04 UNIT HOLDER MICX
678 1C J42-0083-05 POWER CORD BUSHING
679 2C J19-2598-05 UNIT HOLDER
- J61-0098-05 WIRE BAND KPY
- J61-0307-05 WIRE BAND MICX
680 2A ✽ K29-6660-04 KNOB
681 2A ✽ K29-6661-02 KNOB KPY
681 2A ✽ K29-6779-02 KNOB MICX
682 2A ✽ K29-6662-02 KNOB KPY
682 2A ✽ K29-6780-02 KNOB MICX
690 1B ✽ L07-2327-05 POWER TRANSFORMER KP
690 1B ✽ L07-2328-05 POWER TRANSFORMER Y
690 1B ✽ L07-2331-05 POWER TRANSFORMER CX
690 1B ✽ L07-2332-05 POWER TRANSFORMER MI
693 1A T90-0809-05 LEAD WIRE ANTENNA MICX
693 1A T90-0810-05 LEAD WIRE ANTENNA KPY
694 1A T90-0820-05 LOOP ANTENNA
601 1B A01-3432-01 METALLIC CABINET
602 1A A09-0378-08 BATTERY COVER (V150) ET
602 1A A09-0379-08 BATTERY COVER (V300/350) ETMICX
605 2A A46-0303-01 REAR COVER
607 2A A29-0861-01 PANEL ET
607 2A A29-0881-01 PANEL MICX
608 2A ✽ A21-1953-03 DRESSING PANEL (V150) ET
608 2A ✽ A21-1954-03 DRESSING PANEL MICX
608 2A A21-1955-03 DRESSING PANEL (V350) ET
609 2B ✽ A60-1144-01 PANEL ET
609 2B ✽ A60-1145-01 PANEL MICX
610 1A ✽ A70-1136-05 REMOTE CONTROLLER ASSY(V150) ET
610 1A A70-1137-05 REMOTE CONTROLLER ASSY(V350) ET
610 1A A70-1159-05 REMOTE CONTROLLER ASSY(V300) MICX
620 2A ✽ B10-2384-04 FRONT GLASS MICX
621 2B ✽ B03-3802-13 DRESSING PLATE MICX
621 2B ✽ B03-3803-03 DRESSING PLATE ET
622 2A B10-2349-02 FRONT GLASS ET
622 2A ✽ B10-2382-02 FRONT GLASS MICX
623 2A B12-0311-04 INDICATOR
624 2A B10-2350-04 FRONT GLASS ET
624 2A ✽ B10-2383-04 FRONT GLASS MICX
625 B10-2351-04 FRONT GLASS ET
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD ET
- B46-0326-03 WARRANTY CARD C
- B58-0945-03 CAUTION CARD T
- B58-0965-13 CAUTION CARD (PL) T
601 1A
✽ A01-3432-01 METALLIC CABINET
602 1A ✽ A09-0378-08 BATTERY COVER YMICX
602 1A A09-0379-08 BATTERY COVER KP
608 2A ✽ A21-1952-03 DRESSING PANEL
609 2A ✽ A60-1142-01 PANEL KPY
609 2A ✽ A60-1168-01 PANEL MICX
610 1A ✽ A70-1150-05 REMOTE CONTROL ASSY(RC-S503) YMICX
610 1A A70-1159-05 REMOTE CONTROL ASSY(RGC-100) KP
622 2A ✽ B10-2347-02 FRONT GLASS KPY
622 2A ✽ B10-2385-02 FRONT GLASS MICX
623 2A ✽ B12-0311-04 INDICATOR
- B46-0096-53 WARRANTY CARD X
- B46-0326-03 WARRANTY CARD C
- B46-0328-03 WARRANTY CARD KY
- B46-0336-03 WARRANTY CARD P
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0964-13 CAUTION CARD (UL) KY
- B58-0965-13 CAUTION CARD X
- B58-0966-13 CAUTION CARD MI
- B58-0967-03 CAUTION CARD (PL) P
- B58-1546-03 CAUTION CARD C
- B59-1104-00 SERVICE DIRECTORY Y
- ✽ B59-1121-03 SUB-INSTRUCTION MANUAL
- ✽ B59-1122-03 SUB-INSTRUCTION MANUAL
- ✽ B59-1123-03 SUB-INSTRUCTION MANUAL P
- ✽ B59-1129-03 SUB-INSTRUCTION MANUAL C
- ✽ B59-1130-03 SUB-INSTRUCTION MANUAL MI
- ✽ B59-1131-03 SUB-INSTRUCTION MANUAL M
- ✽ B60-3198-00 INSTRUCTION MANUAL(ENG)
- ✽ B60-3199-00 INSTRUCTION MANUAL(FRN) P
- ✽ B60-3200-00 INSTRUCTION MANUAL(SPN) M
- ✽ B60-3201-00 INSTRUCTION MANUAL(TWN) MI
- ✽ B60-3202-00 INSTRUCTION MANUAL(CHN) C
649 1A E03-0115-05 AC PLUG ADAPTER MI
650 1C E30-2592-15 AC POWER CORD MI
650 1C E30-2717-05 AC POWER CORD X
650 1C E30-2787-05 AC POWER CORD KP
650 1C E30-2789-05 AC POWER CORD Y
650 1C E30-2830-05 AC POWER CORD C
651 2B ✽ E35-1772-05 FLAT CABLE (31P)
652 1C ✽ E35-1774-05 FLAT CABLE (15P)
660 1A ✽ F07-1602-04 COVER
- ✽ H10-7286-02 POLYSTYRENE FOAMED FIXTURE KPY
- ✽ H10-7287-02 POLYSTYRENE FOAMED FIXTURE JPY
- ✽ H10-7371-02 POLYSTYRENE FOAMED FIXTURE MICX
- ✽ H10-7372-02 POLYSTYRENE FOAMED FIXTURE MICX
- ✽ H13-0281-04 CARTON BOARD X
- H25-0232-04 PROTECTION BAG (235X350X0.03)
- H25-1516-04 PROTECTION BAG
- ✽ H30-0100-04 ADHESIVE DOUBLE-COATED TAPE KPY
- ✽ H30-0602-04 ADHESIVE DOUBLE-COATED TAPE MICX
- ✽ H50-2334-04 ITEM CARTON CASE KPY
1 2
C-V100
C-V150/V300/V350
