Kenwood CT-203 User Manual

CT-2050/ 203/ KXF-W 6010/ W 4010 (En/ M)
28
Track System ................. 4 track, 2 channel stereo
Recording System .......... AC bias (Frequency: 105 kHz)
Heads ............................... A DECK
Playback/recording heads 1
Erasing head ..................... 1
B DECK
Playback/recording heads 1
Erasing head ..................... 1
Motors.............................. A DECK ............. DC motor × 1
B DECK ............. DC motor × 1
Wow and Flutter ............. ±0.17 % (IEC)
±0.28 % (DIN)
0.1 % (W.R.M.S)
Fast Winding Time ......... Approx. 110 seconds (C-60 tape)
Frequency Response
TYPE
tape .................... 30 Hz to 18,000 Hz, ±3 dB
TYPE
tape .................. 30 Hz to 19,000 Hz, ±3 dB
Signal to Noise Ratio
Dolby NR OFF................ 56 dB
(IEC, 250 nWb/ m, TYPE
tape)
Dolby NR OFF................ 59 dB
Dolby B NR ON .............. 68 dB
Dolby C NR ON .............. 75 dB
(3rd, H.D., 3 %, TYPE
tape)
Harmonic Distortion ....... Less than 1.2 %
(at 315 Hz, 3rd H.D., 250 nWb/ m, TYPE
tape)
Input sensitivity/ Impedance
LINE IN ........................... 122.8 mV/47 kΩ
Output Level/ Impedance
LINE OUT ....................... 775 mV/1.0 kΩ
Headphones................... 0.5 mW/32 Ω
[General]
Power Consumption ...... 30 W
Dimensions...................... W: 440 mm (15-3/4”)
H: 134 mm (5-9/16”)
D: 369 mm (15-3/8”)
Weight (Net) .................... 4.6 kg (10.6 lb)
1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
Specifications
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below. Refer
to the model and serial numbers whenever you call upon your dealer for
information or service on this product.
Model Serial Number
Track System ................. 4 track, 2 channel stereo
Recording System .......... AC bias (Frequency: 105 kHz)
Heads ............................... A DECK
Playback head ................... 1
B DECK
Playback/recording heads 1
Erasing head ..................... 1
Motors.............................. A DECK ............. DC motor × 1
B DECK ............. DC motor × 1
Wow and Flutter ............. ±0.17 % (IEC)
±0.28 % (DIN)
0.1 % (W.R.M.S)
Fast Winding Time ......... Approx. 110 seconds (C-60 tape)
Frequency Response
TYPE
tape .................... 30 Hz to 18,000 Hz, ±3 dB
TYPE
tape .................. 30 Hz to 19,000 Hz, ±3 dB
Signal to Noise Ratio
Dolby NR OFF................ 56 dB
(IEC, 250 nWb/ m, TYPE
tape)
Dolby NR OFF................ 59 dB
Dolby B NR ON .............. 68 dB
Dolby C NR ON .............. 75 dB
(3rd, H.D., 3 %, TYPE
tape)
Harmonic Distortion ....... Less than 1.2 %
(at 315 Hz, 3rd H.D., 250 nWb/ m, TYPE
tape)
Input sensitivity/ Impedance
LINE IN ........................... 122.8 mV/ 47 kΩ
Output Level/ Impedance
LINE OUT ....................... 775 mV/1.0 kΩ
Headphones................... 0.5 mW/32 Ω
[General]
Power Consumption ...... 30 W
Dimensions...................... W: 440 mm (15-3/ 4”)
H: 134 mm (5-9/16”)
D: 369 mm (15-3/8”)
Weight (Net) .................... 4.6 kg (10.6 lb)
CT-2050/KXF-W 6010 CT-203/KXF-W4010
Notes
Notes
