1 Unplug.
2 Lift out the pusher and remove the hopper .
3 Release the lid by sliding the interlock switch back . Lift off
the lid.
4 Lift out the filter .
5 Lift out the pulp collector .
6 Remove the juice jug.
cleaning
●
Before cleaning, unplug your juicer.
●
If the filter is too tight to remove, wait a few minutes until it
loosens up.
●
We don't recommend washing any of the parts in the
dishwasher.
●
Some foods, eg carrot, will discolour the plastic. Rubbing with a
cloth dipped in vegetable oil helps remove discolouring.
motor unit
●
Wipe with a damp cloth, then dry.
pulp collector, lid, pusher, hopper
●
Wash, then dry.
filter
●
Clean using a soft brush.
●
Check the filter regularly for signs of damage. Do
not use if the filter is damaged. Refer to “service
and customer care”
Note: The hopper can be inverted for storage on the juicer
KENWOOD JE550
to take your juicer apart
5
