Kenwood KAC-5202 Service Manual

KAC-5202
3
Parts with the exploded numbers larger than 700 are not supplied.
EXPLODED VIEW
A B
1
2
3
J 2
VR1
S 1
J 1
LINE IN
OPERATION
FILTER
INPUT
SENSITIVITY
J 3
Ex2
Ex2
F
F
Kx7
Jx4
F
F
F
F
F
F
Bx4
Bx4
G
F
Dx2
Dx2
D
D
D
A
C
H
(X09-)
(A/3)
(X09)
(C/3)
(X09)
(B/3)
F1
3
12
2
18
18
23
21
701
716
727
727
727
(X09-)
(X09-)
S 2
(X09-)
(X09-)
WH1
(X09-)
(X09-)
(X09-)
A
B
C
D
E
F
G
H
J
K
4x8
2.6x10
FLAT WASHER
3x10(BLK)
3x6(BLK)
3x8
3x12
M4x8
: N09-4026-05
: N09-4382-05
: N15-1040-46
: N80-3010-45
: N89-3006-45
: N89-3008-46
: N87-3012-46
: N09-4157-05
: N07-0002-08
: N09-4215-08
WH2
(X09-)
G
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood KAC-5202 Specifications

Audio Specifications

max power output	250W
rated power output 4Ω normal	40W x 2
rated power output 4Ω bridge	120W x 1
rated power output 2Ω normal	60W x 2
frequency response	5Hz~50kHz
signal to noise ratio	100dB
sensitivity max rated output	0.2V
sensitivity min rated output	5.0V
input impedance	10kΩ
low pass filter	80Hz

Power

operating voltage	14.4V
current consumption	16A

Weight and Dimensions

dimensions	250 x 52 x 160 mm
dimensions in inches	9-13/16 x 2-1/16 x 6-5/16 inch
weight	2.1kg
weight in pounds	4.6 lbs
