KDC-205/CR, 226
KDC-2026, 3026/R
11
ADJUSTMENT
2. IC10 (TDA7513T) Replacement - Parts vs Adjustment Item Table
• When the parts in the following tables are exchanged, please readjust according to a table.
• When other parts are exchanged, please perform only a check of operation. There is no necessity for readjustment.
Replacement parts Adjustment Item
Parts Name
Ref Number
TYPE Parts Number VCOVt 1st MIX 2nd MIX ANT Coil RF Coil Stereo
IC10 ALL TDA7513T KKKKKK
EEP-ROM M24C01-WMN6T
IC12 ALL BR24C01AF-W KKKKKK
S-24CS02AFJ-TB
Antenna Coil
L505
J L31-0966-05
K
E,K,M L31-0967-05
RF Coil
L506
J L31-0969-05
K
E,K,M L31-0970-05
VCO Coil
L507
J L32-0932-05
K KKKK
E,K,M L32-0936-05
1st MIX Coil L508 ALL L30-0770-05 K
2nd MIX Coil L509 ALL L30-0771-05 K
Variable Capacitance Diodes D504 ALL KV1720S K KKKK
Variable Capacitance Diodes D505 ALL KV1720S K KKKK
Variable Capacitance Diodes D506 ALL KV1720S K KKKK
X'tal X501 ALL L77-2077-05
• The “ K ” mark shows that the adjustment is need.
