37
KDC-205/CR, 226
KDC-2026, 3026/R
Indicates safety critical components.
✽ New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
82AD10-4579-13 LEVER ASS’Y
10 3A D10-4581-13 ARM
11 2A D10-4582-13 ARM
12 3A D10-4583-03 ARM
13 3A D10-4584-03 ARM
14 3B D10-4585-03 ARM
15 2A D10-4586-13 SLIDER
16 3B D10-4587-32 SLIDER
17 3B D10-4588-13 SLIDER
18 3B D10-4595-04 ARM
19 3B D10-4596-14 ARM
22 2A D13-2151-04 GEAR
23 2B D13-2152-04 GEAR
24 3B D13-2153-04 GEAR
25 3B D13-2154-04 GEAR
26 3B D13-2155-04 WORM
27 3B D13-2156-14 GEAR
28 3B D13-2157-04 GEAR
29 3B D13-2158-04 GEAR
30 3B D13-2168-04 GEAR
31 3B D13-2171-04 GEAR
32 2B D13-2172-03 RACK (GEAR)
33 2A D14-0759-04 ROLLER
35 2B D21-2382-04 SHAFT
36 1A D23-0954-04 RETAINER
37 1B D39-0246-05 DAMPER
38 2B G01-3072-04 EXTENSION SPRING
39 2A G01-3073-04 TORSION COIL SPRING
40 2A G01-3074-04 EXTENSION SPRING
41 1B G01-3075-14 EXTENSION SPRING
42 2A G01-3076-04 EXTENSION SPRING
43 1B G01-3077-14 EXTENSION SPRING
44 2B G02-1399-04 FLAT SPRING
45 2B G02-1408-04 FLAT SPRING
51 1A J21-9676-22 MOUNTING HARDWARE
52 3B J21-9677-12 MOUNTING HARDWARE
53 1B J21-9678-13 MOUNTING HARDWARE
55 1A J90-1001-11 GUIDE
56 1B J90-1023-03 GUIDE
DFPC1 3A J84-0141-05 FLAT CABLE (16PIN)
A2BN09-4460-05 TAPTITE SCREW
B1BN09-4472-15 MACHINE SCREW
C2BN09-6004-05 MACHINE SCREW
E2BN09-6007-05 MACHINE SCREW
F1AN09-6051-05 TAPTITE SCREW
G2AN19-2163-04 FLAT WASHER
H1BN39-2020-46 PAN HEAD MACHIN SCREW
J1BN09-6108-05 MACHINE SCREW
DM1 3B T42-1066-04 DC MOTOR ASSY (SPINDLE)
DM2 3B T42-1067-04 DC MOTOR ASSY (LOADING)
DPU1 2B X93-2010-00 OPTICAL PICKUP ASS’Y
MECHANISM ASSY (X92-4840-00)
K2 : KDC-205 K4 : KDC-205CR M : KDC-3026
M1: KDC-2026 M2: KDC-226 M3: KDC-3026R
