22
AUDIO SETTINGS
X ' OVER
TWEETER FRQ
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
5KHZ
/
6.3KHZ
/
8KHZ
/
10KHZ
/
12.5KHZ:
Adjusts the crossover frequency for the tweeter speaker.
GAIN LEFT
–8
to
0
:Adjusts the output volume of the left tweeter.
GAIN RIGHT –8
to
0
:Adjusts the output volume of the right tweeter.
FRONT HPF F - HPF FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ: Adjusts the crossover frequency for the selected
speakers (high pass filter).
;
THROUGH
: All signals are sent to the selected
speakers.
F - HPF SLOPE –6DB
/
–12DB
/
–18DB
/
–24DB: Adjusts the crossover slope.
(Selectable only if a setting other than [
THROUGH
] is selected for [
F - HPF FRQ
].)
F - HPF GAIN –8
to
0
:Adjusts the output volume of the selected speaker.
REAR HPF R - HPF FRQ
(Refer
FRONT HPF
settings above.)
R - HPF SLOPE
R - HPF GAIN
SUBWOOFER
LPF
SW LPF FRQ
30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
: Adjusts the crossover frequency for the subwoofer (low
pass filter).;
THROUGH
: All signals are sent to the subwoofer.
SW LPF SLOPE –6DB
/
–12DB
/
–18DB
/
–24DB: Adjusts the crossover slope.
(Selectable only if a setting other than [THROUGH] is selected for [SW LPF FRQ].)
SW LPF PHASE REVERSE
(180°)/
NORMAL
(0°): Selects the phase of the subwoofer output to be
in line with the speaker output for optimum performance.
SW LPF GAIN –8
to
0
:Adjusts the output volume of the subwoofer.
• (For / )
[
SUB-W LEVEL
]/ [
SUBWOOFER SET
]/ [
SUBWOOFER
] of [
SPEAKER SIZE
]/ [
SUBWOOFER LPF
] of [
X ‘ OVER
] is
selectable only if [
SWITCH PREOUT
] is set to [
SUB-W
].
(
4
)
•
[
SUB-W LEVEL
]/ [
SUBWOOFER
] of [
SPEAKER SIZE
]/ [
SUBWOOFER LPF
] of [
X ‘ OVER
] is selectable only if
[
SUBWOOFER SET
] is set to [
ON
].
• [TWEETER]
,
[REAR HPF]
and
[SUBWOOFER LPF]
of
[X ‘ OVER]
is selectable only if a setting other than
[NONE]
is
selected for
[TWEETER]
,
[REAR]
and
[SUBWOOFER]
of
[SPEAKER SIZE]
.
DISPLAY SETTINGS
Set the dimmer
Press and hold DISP (DIMMER) to turn on or off the
dimmer.
• If you have set [
DIMMER TIME
] (
23
), it will be canceled
once you press and hold this button.
Other settings
1
Press the volume knob to enter [
FUNCTION
].
2 Turn the volume knob to select [
DISPLAY
], then
press the knob.
3 Turn the volume knob to select an item (
23
),
then press the knob.
4 Repeat step 3 until the desired item is selected/
activated or follow the instructions stated on the
selected item.
5 Press and hold to exit.
To return to the previous setting item, press
.
(For / / )
