R-A100/A150/V300/V350
10
ADJUSTMENT
No.
ITEM
INPUT
SETTING
OUTPUT
SELECTOR
TUNER/AMP
SETTING
ALIGNMENT
POINTS
ALIGN FOR
FIG.
FM SECTION SELECTOR : FM
1
DISCRIMINATOR
L31↔L32
(E, T only)
(A)
98.0MHz
1kHz, ±40kHz dev
(E, T type)
60dBu (ANT INPUT)
Connect a DC
voltmeter between
port of CN2
AUTO
98.0MHz
L31 (X05-)
0V
(a)
(B)
L32 (X05-)
Minimum
distrotion
2
DISTORTION
(STEREO)
(C)
98.0MHz
1kHz, ±40kHz dev
pilot: ±6kHz dev
60dBu (ANT INPUT)
(B)
AUTO
(98.0MHz)
IFT (W02-)
Mininum
distrotion
(a)
AUDIO SECTION R-A100/A150 ONLY
1
B CLASS
IDLE CURRENT
–
Connect a DC
voltmeter
Volume:
Minimum
Selector:
any modes
other than
TUNER
CN31 : Lch
CN32 : Rch
13mV
(b)
TAPE1/MD
TAPE 2(MONITOR)
LD VCRCD AUX
IN IN IN
REC PLAY
REC REC
AUDIO
PLAY
PLAY
R
L
SYSTEM CONTROL
SUB
WOOFER
PRE OUT
ANTENNA
AM
FM 75Ω
GND
75µs
FM100kHz
AM 10kHz
50µs
FM50kHz
AM 9kHz
DE- EMPHASIS
CHANNEL
SPACE
+
−
SPEAKERS ( 6-16 Ω)
R
L
AC 220-
240VÓ
AC 110-
120VÓ
UNSWITCHED
Oscilloscope
Distortion meter
AC voltmeter
Dummy antenna
(B)
(A)
(C)
(D)
AG
AG
FM SG
MPX
AG
FM SG
AM SG
(a)
(b)
DC Voltmeter
13mV
CN31(L)
CN32(R)
12
+
-
R-A100/V300(k)1P 98.4.25 11:36 y[W 19
