TH-K2AT/K2E/K2ET
17
∗
New Parts. indicates safety critical components.
Parts w ithout Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. w erden nicht geliefert.
L:
Scandinavia
K:
USA
P:
Canada
Y:
PX (Far East, Hawaii)
T:
England
E:
Europe
Y:
AAFES (Europe)
X:
Australia
M:
Other Areas
Parts No. Description
Address
New
parts
Destination Destination
TH-K2AT/K2E/K2ET
Ref. No.
Parts No. Description
Address
New
parts
TH-K2AT/ K2E/ K2ET (Y50-580X-XX)
TX-RX UNIT (X57-674X-XX)
Ref. No.
PARTS LIST
E : TH-K2E K : TH-K2AT M : TH-K2AT
E3 : TH-K2ET K2 : TH-K2AT M2 : TH-K2AT
1 3A,2G * A02-3817-02 CABINET ASSY(BATTERY CASE) K2,M 2
21C*A02-3818-23 CABINET ASSY(4KEY) E
31A*A02-3819-23 CABINET ASSY(16KEY) K,K2,M
31A*A02-3819-23 CABINET ASSY(16KEY) M 2,E3
4 3A,3C * A10-4066-11 CHASSIS
5 3B,3D * A82-0053-02 REAR PANEL
6 1B,1D * B09-0675-03 CAP(SP/ M IC/ DC IN)
7 1A,1C * B10-2746-03 FRONT GLASS
8 1B,1D * B11-1805-03 ILLUM INATION GUIDE(LCD)
9 2B,2D * B11-1806-04 FILTER(LCD)
10 1B,1D * B38-0881-05 LCD
11 1G * B62-1695-00 INSTRUCTION M ANUAL(CHINESE) M 2
11 1E,1G * B62-1696-00 INSTRUCTION M ANUAL(ENGLISH)
11 1E,1G * B62-1697-00 INSTRUCTION M ANUAL(SPANISH) K,K2,E
11 1E * B62-1697-00 INSTRUCTION M ANUAL(SPANISH) E3
11 1E * B62-1699-00 INSTRUCTION M ANUAL(GERM AN) E,E3
11 1E * B62-1702-00 INSTRUCTION M ANUAL(ITALIAN) E,E3
11 1E * B62-1757-00 INSTRUCTION M ANUAL(FRENCH) E,E3
11 1E * B62-1758-00 INSTRUCTION M ANUAL(DUTCH) E,E3
12 3A * B72-2128-04 M ODEL NAM E PLATE(TH-K2AT) K,K2,M
12 3A * B72-2128-04 M ODEL NAM E PLATE(TH-K2AT) M 2
12 3C * B72-2129-04 M ODEL NAM E PLATE(TH-K2E) E
12 3A * B72-2193-04 M ODEL NAM E PLATE(TH-K2ET) E3
13 2B,2D * E04-0443-05 RF COAXIAL RECEPTACLE(SM A)
14 2A,2C * E23-1234-04 TERM INAL(BATTERY)
15 2B,2D * E29-1199-04 INTER CONNECTOR(LCD)
16 1A,1C * E37-1106-05 LEAD W IRE WITH CONNECTOR(SP)
17 2A,2C * F10-2464-04 SHIELDING COVER(FINAL FET)
18 2A,2C * F10-2465-04 SHIELDING COVER(ANT TERM INAL)
19 2B,2D * F15-1008-04 SHADOW PLATE(LCD)
-*G10-1317-04 FIBROUS SHEET(SP NET)
21 3B,3D G53-1529-04 PACKING(VOL/ENC)
22 2A,2C * G53-1572-02 PACKING(CASE)
23 2B,2D * G53-1589-03 PACKING(SP/ M IC)
24 3E * H52-1960-02 ITEM CARTON CASE(TH-K2AT) K,M
24 3E * H52-1961-02 ITEM CARTON CASE(TH-K2E) E
24 3E * H52-1962-02 ITEM CARTON CASE(TH-K2ET) E3
25 2H * H52-2009-02 ITEM CARTON CASE(TH-K2AT) K2,M 2
26 2F * H12-3146-01 PACKING FIXTURE K,M ,E
26 2F * H12-3146-01 PACKING FIXTURE E3
27 3G * H12-3147-03 PACKING FIXTURE K2,M 2
28 2A,2C * J19-5451-03 HOLDER(TERM INAL)
29 1B,1D * J21-8456-03 HARDW ARE FIXTURE(LCD)
30 2E,3G * J29-0709-04 BELT HOOK ASSY ACCESSORY
31 2A,2C * J30-1284-04 SPACER(PTT KNOB)
32 3E,2G J69-0342-05 HANDSTRAP ACCESSORY M ,M 2,E
32 3E J69-0342-05 HANDSTRAP ACCESSORY E3
33 2B,2D J82-0076-05 FPC(VOL/ ENC)
45 3A,3C J99-0376-04 ADHESIVE TAPE
34 1B,1D K29-5150-03 KNOB(VOL)
35 1B,1D K29-5159-03 KNOB(ENC)
36 1A * K29-9272-02 KEY TOP(16KEY) K,K2,M
36 1A * K29-9272-02 KEY TOP(16KEY) M 2,E3
37 1A,1C * K29-9274-03 KNOB(PTT/ LAM P/ M ONI)
38 1C * K29-9276-02 KEY TOP(4KEY) E
A 2B,2D N09-1492-05 PAN HEAD SCREW (SM A)
B 1B,1D N14-0569-04 CIRCULAR NUT(VOL/ ENC)
C 1B,1D N14-0573-04 CIRCULAR NUT(SM A)
D 1A,1C N79-2035-46 PAN HEAD TAPTITE SCREW (PCB)
E 2A,2C N79-2040-45
PAN HEAD TAPTITE SCREW(HOLDER,R PANEL)
F 3A,3C N82-2007-46 PAN HEAD TAPTITE SCREW (CASE)
G 2A,2C N09-2433-05
PAN HEAD TAPTITE SCREW(FINAL FET)
39 2B,2D R39-0602-05 VARIABLE RESISTOR
40 1A,1C T07-0341-15 SPEAKER
41 2F,3G * T90-1018-25 HELICAL ANTENNA ACCESSORY
42 2F * W 08-0959-15 CHARGER(230V/ 13.8V) ACCESSORY M ,E,E3
43 2E * W08-0960-15 CHARGER(120V/ 13.8V) ACCESSORY K
44 2E * W09-0991-05
BATTERY ASSY(7.2V/ 1100M AH) ACCESSORY
K,M ,E
44 2E * W09-0991-05
BATTERY ASSY(7.2V/ 1100M AH) ACCESSORY
E3
D40 B30-2156-05 LED(RED)
D41 B30-2157-05 LED(YELLOW )
D42-44 B30-2205-05 LED(YG) E3
D42-44 B30-2205-05 LED(YG) K,K2,M
D42-44 B30-2205-05 LED(YG) M 2
D42,43 B30-2205-05 LED(YG) E
D46 B30-2205-05 LED(YG) E
D46,47 B30-2205-05 LED(YG) E3
D46,47 B30-2205-05 LED(YG) K,K2,M
D46,47 B30-2205-05 LED(YG) M 2
D48,49 B30-2237-05 LED(YG)
C1 CK73HB1C103K CHIP C 0.010UF K
C2 CK73HB1H102K CHIP C 1000PF K
C3 CC73GCH1H030B CHIP C 3.0PF B
C4 CK73HB1H102K CHIP C 1000PF K
C5 CK73HB1A104K CHIP C 0.10UF K
C6 CK73HB1H102K CHIP C 1000PF K
C7 CC73HCH1H0R5B CHIP C 0.5PF B
C8,9 CC73GCH1H270G CHIP C 27PF G
C10 CK73HB1C103K CHIP C 0.010UF K
C11 CK73HB1H102K CHIP C 1000PF K
C13 CC73GCH1H0R5B CHIP C 0.5PF B
C14 CK73HB1H102K CHIP C 1000PF K
C15 CC73HCH1H120J CHIP C 12PF J
C17,18 CK73HB1H102K CHIP C 1000PF K
C19 CC73HCH1H150J CHIP C 15PF J
C20 CC73HCH1H080D CHIP C 8.0PF D
C21 CK73HB1H102K CHIP C 1000PF K
C22 CC73HCH1H180J CHIP C 18PF J
C24-26 CK73HB1H102K CHIP C 1000PF K
C27 C92-0628-05 CHIP-TAN 10UF 10W V
C30 CK73HB1H102K CHIP C 1000PF K
TX-RX UNIT (X54-674X-XX)
0-11 : K, K2 0-21 : M, M2 2-71 : E 2-72 : E3
