KRF-V7030D/V8030D/VR-407/409
49
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R36 ,37 RK73FB2A104J CHIP R 100K J 1/10W
R38 -43 RK73FB2A103J CHIP R 10K J 1/10W
R44 -49 RK73FB2A101J CHIP R 100 J 1/10W
R50 RK73FB2A272J CHIP R 2.7K J 1/10W
R51 RK73FB2A102J CHIP R 1.0K J 1/10W YMI
R52 ,53 RK73FB2A272J CHIP R 2.7K J 1/10W
R54 ,55 RK73FB2A103J CHIP R 10K J 1/10W YMI
R54 ,55 RK73FB2A472J CHIP R 4.7K J 1/10W X
R57 ,58 RK73FB2A223J CHIP R 22K J 1/10W
R59 -63 RK73FB2A104J CHIP R 100K J 1/10W
R64 RK73FB2A101J CHIP R 100 J 1/10W
R65 ,66 RK73FB2A103J CHIP R 10K J 1/10W
R67 RD14NB2E222J RD 2.2K J 1/4W YMI
R71 ,72 RK73FB2A473J CHIP R 47K J 1/10W
R83 RK73FB2A564J CHIP R 560K J 1/10W
R86 RD14NB2E152J RD 1.5K J 1/4W YMI
R98 RK73FB2A104J CHIP R 100K J 1/10W
R107-109 RK73FB2A104J CHIP R 100K J 1/10W
R110 RK73FB2A1R0J CHIP R 1 J 1/10W EE1T
R111 RK73FB2A101J CHIP R 100 J 1/10W EE1T
R112 RK73FB2A473J CHIP R 47K J 1/10W EE1T
R113 RK73FB2A101J CHIP R 100 J 1/10W EE1T
R114 RK73FB2A104J CHIP R 100K J 1/10W
R118 RK73FB2A104J CHIP R 100K J 1/10W
R119-126 RK73FB2A101J CHIP R 100 J 1/10W
R127-129 RK73FB2A104J CHIP R 100K J 1/10W
R130 RK73FB2A102J CHIP R 1.0K J 1/10W
R141,142 RK73FB2A104J CHIP R 100K J 1/10W
R143 RK73FB2A101J CHIP R 100 J 1/10W
R151,152 RK73FB2A101J CHIP R 100 J 1/10W
R153,154 RK73FB2A104J CHIP R 100K J 1/10W
R155 RK73FB2A101J CHIP R 100 J 1/10W
R156-158 RK73FB2A750J CHIP R 75 J 1/10W
R161,162 RK73FB2A104J CHIP R 100K J 1/10W
R501,502 RK73FB2A104J CHIP R 100K J 1/10W
W503 R92-0679-05 CHIP R 0 OHM
W505 R92-0679-05 CHIP R 0 OHM YMIX
W507 R92-0679-05 CHIP R 0 OHM EE1T
W509 R92-0679-05 CHIP R 0 OHM
W514 R92-0679-05 CHIP R 0 OHM
S4 -16 S70-0031-05 TACT SWITCH
S19 S68-0107-05 PUSH SWITCH EE1T
S19 S68-0107-05 PUSH SWITCH YMIX
S1 T99-0602-05 ROTARY ENCODER
S2 ,3 ✽ T99-0630-05 ROTARY ENCODER
D7 HZS6.2N(B2) ZENER DIODE
D7 MTZJ6.2(B) ZENER DIODE
D8 ,9 RB721Q DIODE
D11 ,12 MA111 DIODE
D13 HSS104A DIODE KPK1
D13 1SS133 DIODE KPK1
D15 ,16 MA111 DIODE
D17 -22 HSS104A DIODE
D17 -22 1SS133 DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
¢
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C31 CC73FCH1H101J CHIP C 100PF J EE1T
C32 CE04RW0J220M ELECTRO 22UF 6.3WV
C33 -35 CC73FCH1H101J CHIP C 100PF J
C36 ,37 CC73FCH1H470J CHIP C 47PF J
C38 ✽ CE04RW1H330M ELECTRO 33UF 50WV
C39 CK73FB1H103K CHIP C 0.010UF K
C40 C90-1826-05 BACKUP-C 0.047F 5.5WV EE1T
C40 C90-1826-05 BACKUP-C 0.047F 5.5WV YMIX
C41 CK73FB1H103K CHIP C 0.010UF K YMI
C42 CK73FB1H103K CHIP C 0.010UF K YMIX
C43 ,44 CC73FCH1H101J CHIP C 100PF J
C45 ,46 CC73FCH1H470J CHIP C 47PF J
C47 CC73FCH1H101J CHIP C 100PF J
C48 CC73FCH1H101J CHIP C 100PF J YMI
C49 CE04RW0J331M ELECTRO 330UF 6.3WV KPK1
C50 CC73FCH1H101J CHIP C 100PF J
C51 ✽ CE04RW1H2R2M ELECTRO 2.2UF 50WV YMI
C52 CK73FB1H103K CHIP C 0.010UF K EE1T
C53 CC73FCH1H101J CHIP C 100PF J
C54 ✽ CE04RW1H4R7M ELECTRO 4.7UF 50WV
C55 CC73FCH1H470J CHIP C 47PF J
C56 CC73FCH1H220J CHIP C 22PF J
C57 CC73FCH1H221J CHIP C 220PF J
C58 CC73FCH1H470J CHIP C 47PF J
C59 CK73FF1C105Z CHIP C 1.0UF Z
C61 CC73FCH1H101J CHIP C 100PF J EE1T
C101-107 CC73FCH1H101J CHIP C 100PF J
CN1 ✽ E40-8510-05 FLAT CABLE CONNECTOR
CN2 ✽ E40-8504-05 FLAT CABLE CONNECTOR
CN3 E40-3247-05 PIN ASSY
CN5 E40-3261-05 PIN ASSY
J1 E11-0272-05 PHONE JACK
J2 E63-1035-05 PIN JACK
J2 ✽ E63-1147-05 PIN JACK
J3 E06-0709-05 CYLINDRICAL RECEPTACLE
- J19-5928-13 HOLDER
- J19-5928-13 HOLDER
E5 ,6 J11-0808-05 WIRE CLAMPER
X1 ✽ L78-0714-05 RESONATOR (8MHZ)
X2 L77-2002-05 CRYSTAL RESONATOR(4.332MHZ) EE1T
CP1 R90-0855-05 MULTI-COMP 100KX5 J
CP2 ,3 R90-0482-05 MULTI-COMP 100KX4 J 1/6W
CP501 R90-0855-05 MULTI-COMP 100KX5 J
CP502 R90-0850-05 MULTI-COMP 100KX3 J 1/6W
R4 RK73FB2A102J CHIP R 1.0K J 1/10W
R5 RK73FB2A103J CHIP R 10K J 1/10W
R7 RK73FB2A104J CHIP R 100K J 1/10W
R8 RK73FB2A102J CHIP R 1.0K J 1/10W
R12 RK73FB2A331J CHIP R 330 J 1/10W
R13 ,14 RK73FB2A104J CHIP R 100K J 1/10W
R15 RK73FB2A331J CHIP R 330 J 1/10W
R29 RK73FB2A122J CHIP R 1.2K J 1/10W
R30 -34 RK73FB2A221J CHIP R 220 J 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
£
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
