KERN FKB 8k0.05 Operating Manual

FKB-BA-e-2010 7
KERN FKB 36K0.2 FKB 65K1 FKB 65K0.2
Item no./ Type TFKB 36K-4B-A TFKB 65K-3-A TFKB 65K-4-A
Readability (d) 0.0002 kg 0.001 kg 0.0002 kg
Weighing range (max) 36 kg 65 kg 65 kg
Taring range (subtractive) 36 kg 65 kg 65 kg
Reproducibility 0.0002 kg 0.001 kg 0.0002 kg
Linearity ± 0.0006 kg ± 0.003 kg ± 0.0006 kg
Stabilization time (typical) 3 sec.
Smallest part weight for
piece counting - under lab
conditions*
200 mg 2 g 200 mg
Smallest part weight for
piece counting - under
normal conditions**
2 g 20 g 2 g
Adjustment points 10 / 20 / 30 / 36 kg 20/40/60 kg 15 / 30 / 50 / 60 kg
Recommended adjusting
weight F1 (not supplied)
20 kg; 10 kg (F1) 60 kg (F2) 50 kg; 10 kg (E2)
Warm-up time 2 hrs.
Weighing Units kg, g, gn, dwt, ozt, lb, oz
Humidity of air max. 80% rel. (non-condensing)
Allowable ambient
temperature
-10 °C ... + 40 °C
Input voltage Appliance 9 V, 1 A
Input voltage Mains
adapter
100 V - 240V AC 50/60Hz 0.3A
Batteries (option) 6 x 1.5V AA
Storage battery operation
(optional)
Operating period 90 h (background illumination OFF)
Operating period 40 h (background illumination ON)
Loading time approx. 10 hrs.
Auto-Off (battery,
rechargeable battery)
3 min
Auto off (net)) Selectable 30s, 1, 2, 5, 30, 60 min
Dimensions caisse
(l x L x h) [mm]
350 x 390 x 120
Weighing pan stainless
steel mm
340 x 240
Net weight (kg) 7 6 7
Interfaces
• RS-232 (DB9 female), as per series
• USB-appliance connection (USB B), Factory option
• Ethernet, Factory option
• WLAN, Factory option
Underfloor weighing device yes (hook supplied)
