Kobalt KPC 2040-06 User Manual

6
ASSEMBLY INSTRUCTIONS
1 . INSTALL THE SPRAY WAND
• Push the end of the spray wand (B) into the gun handle
(C).
• Turn the spray wand (B) clockwise until the tabs lock
into position.
2 . INSTALL THE SPRAY NOZZLE
• Pull back the quick-connect collar on the spray wand
(B).
• Insert the spray tip (A) onto the spray wand (B).
• Release the quick-connect collar to attach the spray tip
(A).
• Pull on spray tip (A) to ensure it is properly installed
and does not pull out.
3. INSTALL THE SELF-SIPHON HOSE
• Insert one end of the self-siphon hose (G) into the water
intake (D).
A
2
1
2
3
B
3
G
D
1
C
B

Kobalt KPC 2040-06 Specifications

General

Brand	Kobalt
Model	KPC 2040-06
Category	Pressure Washer
Language	English
